Stump Chimney™
Instructions
Stump Chimney™, the environmentally friendly stump remover,
is a Swedish product that is patented and manufactured in
Sweden.
Read the full description before you start.
Components
These are needed in addition to a Stump
Chimney™
Assembly
1. Assemble the sides
1. Always start with side A. Insert the tongues of Side B into
the slits of Side A. The air holes should always be located
on the bottom.
2. Insert the staple into the hole on the tongue. Each tongue
must be locked with a staple. Then continue to assemble
the sides. Alternate between Side A and Side B.
3. If the ground is uneven or if there are many roots, one or
several sides can be mounted higher up or lower down than
the adjacent sides. It is sufficient that two of the three
tongues are fastened in a slot.
The number of sides depends on the size and appearance of
the stump. The ideal gap between the stump and the Stump
Chimney™ is 1 briquette. If the gap is too large, many more
briquettes are to be used and less heat is generated around the
stump.
See more under Number of sides to a stump under other
information.
____________________________
2. Attach the folding plates
When the sides are connected into a circle, the folding plates
can be mounted.
1. The folding plate is inserted into the horizontal slots from the
inside.
2. Bend up the middle tongue on the outside of the chimney.
3. The angle of the folding plate should be about 60 degrees
when hanging freely.
4. Repeat this process until all Side A and Side B have a
folding plate attached to it.
____________________________
3. Lock the folding plates in the upright position
1. Fold the folding plate on the inside so that it points straight
up.
2. Insert the Hook from the outside, into the slot above the
folding plate attachment.
3. Insert the hook until it can be lowered and lock the folding
plate.
This is done to make it easier when adjusting the Stump
Chimney™ over the stump and when filling in the grill
briquettes.
Video for Assembly
Watch a video on how to assemble the Stump
Chimney™ by visiting
www.stumpchimney.com/assemble-stump-chimney/
or scanning the QR code
Page 1 (4)
Advertisement
Table of Contents
Summary of Contents for Stump Chimney Stump remove
- Page 1 Stump Chimney™, the environmentally friendly stump remover, See more under Number of sides to a stump under other is a Swedish product that is patented and manufactured in information.
- Page 2 A. Place the Stump Chimney™ over the stump. If there are roots protruding from the stump, they can either be cut off or the sides of the Stump Chimney can be adjusted in height. It is important that the Stump Chimney™ stands firmly on the ground and does not topple over.
- Page 3 3. Let the fire burn for 1.5 - 2 hours 6. When the stump has burned up Once the stump has burned up, simply lift off the Stump Chimney™. As the briquettes burn up, the patented folding plates will fold in ____________________________ towards the stump, bringing pre-heated air towards the stump, 7.
- Page 4 Always make sure to use plenty of water once the stump has burned down. Examine the soil conditions, peat-rich soil must be damp. If there is a lot of wind, the Stump Chimney™ should not be used. Even if there is no fire ban in place, an assessment must be made as to whether or not it is appropriate to burn it.
