LINKD Alarms LINKD201 Information Sheet

Information Sheet
LINKD201 - Smoke Alarm

Contents:-

• • 1 x LINKD201 Smoke Alarm 1 x LINKD201 Smoke Alarm
• • 1 x Battery (sealed & tamper proof) 1 x Battery (sealed & tamper proof)
• • 1 x Mounting Bracket 1 x Mounting Bracket
• • 2 x Wall Plugs, 2 x Screws 2 x Wall Plugs, 2 x Screws
• • 1 x Adhesive Pad 1 x Adhesive Pad

Where to install your smoke alarm:-

Scottish law states the following:-
"One interlinked smoke alarm in your living
room or the room you use the most. One
interlinked smoke alarm in each hall or landing
on each level"
Additional smoke alarms can be added to your
system and installed in additional locations at
your discretion.
Please note - We recommend that each alarm
is placed no more than 20m from the next
closest alarm to ensure there is no signal loss.

Locations to avoid:-

• In turbulent wind-streams of air such as
close to fans
• In high humidity areas such as bathrooms
and shower rooms
• At the apex of an "A" frame celling.
"Dead air" at the top may prevent smoke
from reaching the alarm in time to
provide an early warning
• Less than 12 inches or 300mm from the
wall when mounted on the celling
• In insect infested areas as, tiny insects
may affect performance
• In kitchens, boiler rooms, laundry rooms,
garages. Combustion particles from
cooking or car exhausts and dust and
moisture could trigger the alarm
• In very dirty or dusty areas. Dirt and dust
can build up and effect performance
• Within 12 inches or 300mm of light fittings
or room corners
• In locations which could make testing
hazardous (such as over a stairwell)
• Near objects such as celling decorations
which might impede the path of smoke to
the alarm
• Less than 12 inches or 300mm from the
wall when mounted on the celling
• Within 5 feet or 1500mm of fluorescent
lighting
Determine the location where you wish to
install your alarm. It is advisable to install the
alarm in a central location and to avoid areas
where there is low air circulation (i.e. corners
of room, next to large items that may block air
flow)
• Choose between the Adhesive Pad or
Screws
• If using the pad - wipe both the wall and
alarm to ensure they are free from dust
• Remove the backing from one side
and stick it to the bracket. Remove the
backing from the other side and stick it to
the wall
• If using screws - check which screws
and wall plugs are most suitable for your
chosen location
• Fix the bracket into the wall using the wall
plugs and screws
• Click the alarm into the bracket

Limitations of smoke alarms:-

Smoke alarms play a vital role in reducing
deaths caused by fires worldwide. However,
like any warning device, smoke alarms can
only work if they are properly located, installed
and maintained.
Smoke alarms may not wake all individuals.
Smoke alarms cannot detect fires if the smoke
doesn't reach the alarm.
Smoke alarms may not have time to sound
before the fire itself causes damage, injury or
