WARNINGS

Before using your new Steren product, read this manual to avoid any malfunction.
The information presented serves only as a reference for the product. Due to updates there may be differences.

This product is not a toy; Keep out of children reach.
Do not use or store the product in places where there are leaks or splashes.
Do not expose the equipment to extreme temperatures.
Do not use the headphones at high volume level for a long time, it could damage the hearing.
Do not try to open the product. Contact the distributor if you have any questions.

Operation of this equipment is subject to the following two conditions:

this device or device may not cause harmful interference, and
this device or device must accept any interference, including interference that may cause undesired operation.

CONTENT

PARTS

BATTERY CHARGE

Charge the battery for 2 hours for optimal operation. While charging, the indicator LED will light in red, when it is fully charged it will remain lit in blue.

Option 1

Pull the protective plastic from the micro USB charging port in the earphone.
Connect the micro USB cable to the micro USB port on the earphone and the other end to an USB charging port

Option 2

Connect the micro USB cable to the micro USB port of the earphone and the other end to an USB adapter (not included) and connect it to an electrical outlet.

CONNECTION

Turn on and connect the earphones

Put on your earphones to listen the voice messages.
To turn them on, press and hold the multifunction buttons simultaneously until you hear the message:
"Connected". The earphones will connect to each other and will be identified as follows:
Left channel: Works as main earphones
Right channel: It works as a secondary hearing aid
The indicator of one of the earphone will flash blue, while the other alternate in blue and red
In the list of Bluetooth devices in your smartphone, search and select STEREN AUD-7510. If the connection is successful, the indicators in both earphones will flash in blue.

Whenever they are turned on, the earphones will automatically pair to the last device. If you want to use only one earphone turn them off and turn on only the one you want to use.

Press and hold the multifunction button until you hear the message: "Power off" to turn off the earphone.

HOW TO USE

Operation may vary depending on the operating system and the model of the connected device.

You can use one or both earphones. In case the two are connected, the left will always work as the main one.
Press the multifunction buttons as indicated below to control music or calls.

Music reproduction

Left / Right: Play / Pause

Control the volume from your smartphone

Hands free

Only the voice will be heard in the main earphoned (in case one earphones aid is used, the hands-free function can be used in either one.)

Press once to answer / hang up a call
Press the multifunction button twice to call the last dialed number.

If this pressure time is exceeded in the button the hearing aid will turn off

SPECIFICATIONS

Operating frequency: 2.4 GHz
Input: 5 V 200 mA (x USB)
Battery life: 3 h
Operating temperature: -20 to 60°C
Internal battery: 3.7 V 40 mAh

Earphone
Frequency response: 20 – 20 000 Hz
Driver unit: 10 mm
Impedance: 16 Ohms
Sensitivy: 87 ± 3dB @ 1 kHz
Maximum power output: 3 mW

Microphone
Sensitivity: -40 ± 3dB
Frequency response: 70 Hz – 16 kHz
Impedance: ≤ 2.2 kOhm

WARRANTY

This Steren product is warranted under normal usage against defects in workmanship and materials to the original purchaser for three months in her battery and one year on the other parts from the date of purchase.

This warranty card with all the required information, invoice or purchase ticket, product box or package, and product, must be presented when warranty service is required.
If the product is in the warranty time, the company will repair it free of charge.
The repairing time will not exceed 30 natural days, from the day the claim was received.

In case your product fails or have questions, please contact your nearest dealer.
If you are in Mexico, please call to our Call Center.
01 800 500 9000

www.steren.com
