End pendant
assembly
Yoke arm
10-32 x5/8"
End screw
ADY071477 REV A (ECN080352)
Exploded view and part call-out
J-box
(by others)
Pendant tube
Pendant nut
(x2)
Swivel pendant shown
Center pendant
assembly
Fixture wire
Center cover plate
Pendant tube
Power wire
from J-box
#10-32 x 5/8"
End screw
(2x)
#10-32 x 3/8"
Pan head screws
(2x)
Advertisement
Related Manuals for Ametrix CPP/CPS
Summary of Contents for Ametrix CPP/CPS
- Page 1 End pendant Pendant tube assembly Pendant nut (x2) Yoke arm 10-32 x5/8" End screw ADY071477 REV A (ECN080352) Exploded view and part call-out J-box (by others) Center pendant assembly Fixture wire Center cover plate Swivel pendant shown Pendant tube Power wire from J-box #10-32 x 5/8"...
- Page 2 #8-32 x1/2" Screw (2x) Pendant yoke #10-32 x5/8" End Screw 1. Secure pendant yoke to pendant tube using both pendant nuts prior to installation. J-box (by others) PS mounting plate ADY071477 REV A (ECN080352) PP mounting plate #8-32 x1/2" Screw (2x) PP canopy Pendant yoke...
- Page 3 " " 36.95 49.43 32 " 127.84 16 " 8.25 32 " 105.71 ADY071477 REV A (ECN080352) 2ft fixture 8 " 733.40 3ft fixture 32 " 1036.22 4ft fixture 8 " 1343 " 4.86 32 " 14.99 " 8 3.30 "...
- Page 4 Securing first fixture to first pendant Canopy #10-32 x5/8 End screw 1. Choose first fixture in run. First fixture depends on length of run, refer to page four(4) for fixture identification. The final fixture will have to have the extra wire capped off. 2.
- Page 5 Actual Overall Nominal Length: Length Pendant Row Breakdown/ (ft) (ft) Installation Sequence 2C,2C 2C,3C 3C,3C 3C,4C 4C,4C 10.7 3C,3C,3C 11.7 4C,2C,4C 12.7 4C,3C,4C 13.7 4C,4C,4C 14.2 3C,3C,3C,3C 15.2 3C,3C,3C,4C 16.2 3C,4C,4C,3C 17.2 4C,4C,4C,3C 18.2 4C,4C,4C,4C 19.8 4C,3C,3C,3C,4C 20.8 3C,4C,4C,4C,3C 21.8 4C,4C,3C,4C,4C 21.8 4C,4C,3C,4C,4C...
