LUXE BIDET Glantis Installation Manual

LUXE BIDET Glantis Installation Manual

Bathroom cabinet

Advertisement

Quick Links

Warranty:
12-Month Limited Warranty to the original buyer from date of purchase that the cabinets will be free from defects
in material and workmanship under normal use.
Installa�on Manual
Read manual prior to installa�on for important
informa�on about safety, installa�on, use, and
maintenance.
Follow instruc�ons for proper assembly.
Assemble on carpet free of debris to prevent
scratching. Do not subs�tute parts. Do not
over�ghten screws. Do not use if broken or
damaged.
Assembly should be carried out by a qualified
person. Incorrect assembly may lead to furniture
�p-over and may cause injury or damage.
Warning
Serious or fatal injury can occur from
furniture tip-over. To prevent tip-over,
permanently attach product to wall or
floor with included attachment parts.
Fastening components are included,
but consultation with specialized dealer
for advice on suitable screw systems
and fastening devices is recommended.
Safety recommendation:
• Place heaviest items in lowest drawers.
• Do not set heavy objects on top of product.
• Do not allow children to climb or hang on
drawers, doors, or shelves.
• Do not open more than one drawer at a time.
• Use of tip-over restraints may reduce, but not
eliminate, the risk of tip-over.
Use as intended. Inappropriate use may cause
injury or damage.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Glantis and is the answer not in the manual?

Questions and answers

Summary of Contents for LUXE BIDET Glantis

  • Page 1 Installa�on Manual Read manual prior to installa�on for important informa�on about safety, installa�on, use, and maintenance. Follow instruc�ons for proper assembly. Assemble on carpet free of debris to prevent scratching. Do not subs�tute parts. Do not over�ghten screws. Do not use if broken or damaged.
  • Page 2 HOW TO USE CAM SCREW FLAT HEAD CAM LOCK NUT x72 WOOD DOWEL x82 WOOD DOWEL x8 CAM SCREW x72 SCREW x14 #8x35 #6x35 M4x50mm. Turn the Cam Screw or gently tap until the shoulder is against the surface of the part. FLAT HEAD PAN HEAD FLAT HEAD...
  • Page 3 Step 2 Step 4 (5x) WOOD DOWEL M4x16mm. PAN HEAD SCREW (16 used in this step) Arrow (5x) Cam Lock Nut LEG x4 Step 5 Step 3 M4x16mm. FLAT HEAD SCREW (10 used in this step) (5x) WOOD DOWEL L-BRACKET-2 (2 used in this step) (1/4”*2”) Arrow...
  • Page 4 Step 6 Step 8 M4x40mm. FLAT HEAD SCREW (12 used in this step) FLAT HEAD SCREW M5x70mm. PLASTIC PLUG (3 used in this step) Step 7 Step 9 WOOD DOWEL (8x) M4x40mm. FLAT HEAD SCREW M4x40mm. (16 used in this step) FLAT HEAD SCREW (12 used in this step)
  • Page 5 Step 10 Step 12 right drawer glide M3.5x13mm. right drawer left drawer FLAT HEAD SCREW glide glide (6 used in this step) A) Attach drawer assembly to assembled unit: Fit drawer glides of drawer assembly into corresponding drawer glides of unit. Push M6x23mm.
  • Page 6 Step 14 Step 16 M4x50mm. (10x) FLAT HEAD SCREW (4 used in this step) Cam Screw M4x50mm. FLAT HEAD SCREW (6 used in this step) Arrow (14x) WOOD DOWEL (10x) Cam Lock Nut Step 15 Step 17 (4x) WOOD DOWEL (6x) Cam Screw (2x)
  • Page 7 Step 18 Step 20 (2x) LARGE BRACKET M4x16mm. FLAT HEAD SCREW FLAT HEAD SCREW (16 used in this step) M5x50mm. PLASTIC PLUG (6 used in this step) BUMPER CARD (4 used in this step) Step 19 Step 21 M4x16mm. FLAT HEAD SCREW (8 used in this step) (6x) Cam Screw...
  • Page 8 Step 22 Step 24 Arrow (12x) (12x) Cam Lock Nut Cam Screw (2x) LARGE BRACKET (12x) WOOD DOWEL FLAT HEAD SCREW M5x50mm. PLASTIC PLUG (6 used in this step) Step 23 Step 25 M4x16mm. PAN HEAD SCREW (6 used in this step) (2x) LARGE BRACKET...
  • Page 9 Step 26 Step 28 Arrow (28x) (28x) Cam Lock Nut (2x) Cam Screw LARGE BRACKET FLAT HEAD SCREW M5x50mm. (32x) PLASTIC PLUG WOOD DOWEL (12 used in this step) Step 27 Step 29 M4x16mm. M4x16mm. PAN HEAD SCREW FLAT HEAD SCREW (8 used in this step) (12 used in this step) HINGE...
  • Page 10 Step 30 Step 31 M4x16mm. FLAT HEAD SCREW (16 used in this step) BUMPER CARD (4 used in this step)
  • Page 11 WALL ANCHORING GUIDE: Masonry: The hardware you should use to secure your furniture to the wall depends on both the type of furniture you have and your wall material. Type of Wall Material: Using the guide below, identify your wall material and the appropriate steps to take for that wall material.

This manual is also suitable for:

CabglantisnavyCabglantismirroCabglantissides
