Summary of Contents for Motive Cable 3043

  • Page 1 Cable 3043 Vehicle Gateway installation guide for Freightliner 2017 and later trucks...
  • Page 2 • Flashlight (optional). • Dash bezel Instructions Step 1 Ensure the vehicle is safe to install the Motive Vehicle Gateway: • The parking brake is engaged. • The engine is off. • The main power switch (if available) is turned off.
  • Page 3 Step 2 (continued) Step 3 Remove eight T25 screws from the instrumentation panel. Remove the red “Trailer Air Supply” and yellow “Parking Brake” knobs (if present). Place the screws and knobs in a cup labeled “Instrumentation Panel.” Step 4 Remove two T25 screws from passenger dash panel and place in a cup labeled “Passenger Dash Panel.”...
  • Page 4 “Top Panel.” Gently raise the top panel a few inches from its original position. Step 6 Insert the terminated leads of the Motive cable through the top panel. Step 7 Identify a J1939 250K TEM splice pack near the center dashboard (typically splice pack 2/SP2).
  • Page 5 Step 8 Connect the black ground wire to the “GND” TEM splice pack. Connect the red wire to the ”Power Battery” TEM splice pack. Take the 15-pin connector end of the cable and Step 9 place it on top of the dashboard. Secure the wiring and TEM splice packs with zip ties then reattach the panels.
  • Page 6 GNSS connection. Step 12 Once the driver connects to the Vehicle Gateway using the Motive Driver App available on iOS and Android, the right-side indicator light will turn green indicating a successful Bluetooth connection. Please refer to the Motive Driver App Guide for more details on the Motive mobile platform.
  • Page 7 This page is intentionally left blank 855-434-3564 | support@gomotive.com...
  • Page 8 Potential Unlocked gomotive.com FL2017-R04...
