Summary of Contents for JTS PCP HAND PUMP

  • Page 1 pcp hand pump manual...

  • Page 2: Package Contents

    1. PACKAGE CONTENTS PUMP HANDLE X1 SPARE 20MM O’RING X1 PUMP CYLINDER ASSEMBLY X1 SPARE 25MM O’RING X1 HOSE ASSEMBLY X1 BALL INFLATOR ADAPTER X1 DEAD HEAD X1 3MM ALLEN WRENCH X1 ASSEMBLY WRENCH X1 SPARE 5MM O’RING X3 PRESSURE GUAGE X1 SPARE 7MM O’RING X3 CHECK VALVE TOOL X1 SPARE CHECK BALL SPRING X1...
  • Page 3 STEP 3: Attach gauge using assembly wrench STEP 3: Attach fill hose as shown...
  • Page 4 4. USING YOUR HAND PUMP STEP 1: Attach to pressure vessel STEP 2: Ensure the bleed valve has been tightened STEP 3: Place a foot on each base plate and position yourself comfortably and balanced STEP 4: Pull handle vertically applying long steady strokes. Keeping back straight and flexing your knees will help maintain balance.

  • Page 5: Maintenance

    1. MAINTENANCE JTS hand pumps require very little maintenance. We do recommend the inner cylinder be lubricated every 3 months using silicon grease. STEP 1: Raise the pump to very top of its stroke OUTER CYLINDER STEP 2: Apply a small amount of silicon grease to the inner cylinder.

  • Page 6: Troubleshooting Guide

    Do not return defective or damaged products to the place of purchase. If your pump needs repair, call Xisico USA/JTS Airguns @ 281-647-9130 DO NOT ATTEMPT TO DISASSEMBLE IT! Your pump requires special tools and fixtures to repair it. Any disassembly or modification not performed by Xisico...

  • Page 7: 90-Day Limited Warranty

    Replacement parts and labor. WHAT IS NOT COVERED Shipping charges to Xisico USA/JTS Airguns for defective product and damages caused by abuse or failure to perform normal maintenance as well as any other ex- pense. Consequential damages, or incidental expenses, including damage to proper- ty.
  • Page 8 We reserve the right to make color and design changes and technical improvements. No responsibility is accepted for printing errors or incorrect information. Distributed by Xisico USA/JTS Airguns 7724 Cherokee Street Katy, TX 77494 www.jtsairguns.com 0222...
