- Page 1 SVANAR WIRELESS Topology Diaphragm Owner’s Guide RIGHT LEFT 217-230910 217-230897 FCC ID：2BAQY-T050TA201 EARBUD EARBUD...
-
Page 2: Power On/Off
Accessories ④ ③ ① ① ⑤ ⑥ ② ② Touch Pad Microphone Charging Case Indicator Light inside Charging Case Indicator Light outside Charging Case Hard Key Power On/Off The earbuds will instantly power on when removed from the charging case. The earbuds will automatically start recharging when returned to the charging case, and turn off when fully charged. - Page 3 2. Open the Bluetooth function menu on your device and select HIFIMAN SVANAR WIRELESS. Once paired, you will hear "Connected.” Important: You have 3 minutes to connect the earbuds to your device, otherwise the earbuds will exit and automatically power off .
- Page 4 Pairing Forced Reconnection When wearing both earbuds, press and hold both earbuds for 3 seconds at the same time to forcibly cancel the last connected device. After canceling the connection, the headset will enter pairing mode with a voice prompt: "Pairing." Return the earbuds to the charging case, press and hold the hard key of the charging case for 3 seconds while the cover is open.
-
Page 5: Calls & Music
Calls & Music Calls Answer call Double-click either earbud twice to answer the call End call While in a call, double -click either earbud twice to end the call Reject call Press and hold either earbud for ~3 seconds to reject the call Long press the right earbud (R) for ~3 seconds to turn on the voice assistant (Note: the device needs to support the Voice Assistant function.) -
Page 6: Mode Switch
Mode Switch Noise Cancellation/HIFI Mode/ Transparency Mode Only when wearing both earbuds: The initial mode is High Fidelity when SVANAR Wireless is turned on. Press and hold the left earbud for 3 seconds to switch to Noise Cancellation mode, which is accompanied by a voice prompt: "ANC ON."... - Page 7 Charging Charge the Earbuds Low Battery Alert When the battery falls below 10% power, you will hear the "Low battery, please charge" prompt every 2 minutes. Return the earbuds to the charging case . The headset will automatically shut down after it is fully charged. Indicator Light Inside the Charging Case for Earbuds Battery Status Green Light on...
- Page 8 Charging Charge the Charging Case Plug the charging cable into the charger port or place the SVANAR Wireless on a wireless charging plate to charge the charging case and earbuds. When charging, the Indicator Light on the charging box remains illuminated, indicating the battery status of the charging case.
-
Page 9: Specifications
Specifications Earphone Specifications Size 32.2x20.4x29.1mm Single Head Weight 8.0g Earbud Charging Time ~2hrs Work voltage 3.1-4.2V Earphone Input 5 V 85mA MAX up to 4H(HIFI Mode) Play Time up to 6H(ANC Mode) up to 7H(Transparency Mode) ANC Spec up to 35dB Frequency Response 10Hz-35kHz Built-in amp output... -
Page 10: Fcc Radiation Exposure Statement
FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. -
Page 11: Hifiman Limited Warranty
HIFIMAN Limited Warranty Svanar Wireless is warrantied for a period of 18 months beginning with the original date of purchase. If you join the official HIFIMAN group on Facebook, your product warranty will be extended for an additional six months. Please contact HIFIMAN customer service if you need any assistance. - Page 12 5. If you do not have a valid dated receipt showing proof of purchase. 6. Damage caused by services/repairs or other modifications to the system carried out by anyone other than HIFIMAN or an authorized HIFIMAN distributor or dealer. 7. Damage caused by self-repair or if the unit has been disassembled or modified in any way.
- Page 13 Address: 2602 Beltagh Ave, Bellmore, NY 11710, USA...
