FORE SHOT UP-002BT Manual

Manual of Bluetooth Portable Stereo Speaker
UP-002BT

Package Content :

User's Manual :

Instruction :

1 Unlock and twist the right and left speaker.
Lock

Setup

To play audio from a Bluetooth device, you need to pair the device with the speaker. You can pair up to devices.
1. On your Bluetooth device, turn on Bluetooth and scan for devices in its Bluetooth menu.
2. Power On/Off : Push 3 seconds to turn on power
Pairing Mode : When powering up for the first time, push 6 seconds into pairing mode, the speaker is discoverable for 2 minutes and is ready for
pairing. The Status indicator blinks red and blue.
Music NEXT / Previous Bottom : + continuous push / - continuous push
3. When "UP-002BT" appears on the searching list of your Bluetooth device, select the "UP-002BT". The Bluetooth status light turns solid blue after pairing
is established. The speaker is ready to play music.
Note: If pairing times out (the Bluetooth status light stops blinking red and blue), press and hold the Pair/Power button to turn off UP-002BT. Then, repeat
frome step 2.

Charging :

Fully charge the speaker (about 4 hours).
1. Plug the charging cable into the speaker's charging port and the other
end into computer USB port(with the power on) for charging.
Status indicator :
• Pairing Mode : Blue/Red light switch
• Normal Working : Blue light ticking
• Play Music : Blue light on
• Power Shortage : Red light ticking
• Charging : Red light on
The speaker enters power saving mode if no bluetooth signal for 2
minutes. UP-002BT will automatically turn off.

Features :

UP-002BT:
USB Cable:
Pick up the 3.5mm plug from Right speaker, and
2
connect to Left speaker.
Unlock
R
Power LED Indicator
1
The LED indicator will be illuminated
in BLUE to show the power status.
Volume Button
2
Press + or - to adjust the volume.
Power / Pair Button
3
Press the Power button to turn on
and pair with the speaker.

Troubleshooting :

The speaker doesn't work or it won't pair
• Try moving your device closer.
• Is the speaker turned on and charged?
• Turn the speaker off and then on to wake it.
• Is Bluetooth enabled on your device or computer?
• Try repeating the setup procedure in this guide or pair with a different
Bluetooth device.
• The speaker plays music from one device at a time. Unpair the device
not being used. (Refer to your device documentation for help.) Pair a
new device using the setup procedure.
• If pairing with a computer, specify the UP-002BT as the audio out
device on the computer.
• When disconnect the pairing, shoud also remove UP-002BT from your
searching list.
Mantanence :
Under the condition of normal use, please use dry cloth to clean the
appearance of speaker. If necessary, please use cloth with diluted
detergent to clean it. It is prohibited to use wax, detergent, thinner,
gasoline, insecticide or chemical reagent because of causing corrosion
on the surface of the product.
QD ID : B018164
L
L
(Right Side)
1
2
3
4
5
6
3.5Ø Socket
4
The socket for connecting the right
speaker.
Mini USB Port
5
3.5Ø Plug
6
The plug for connecting the left
speaker.
3 Connect to your mobile phone
or computer.
Computer
www.foreshot.com.tw
