EXALUS HOME PX-BIDI Manual

Controllers operate at 868 mhz, 1/12 channel
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

EXALUS TR7
Spółka z ograniczoną odpowiedzialnością sp.k.
Kuchary 24F
63-322 Gołuchów
www.exalus.pl
CHANNEL -
CHANNEL +
EXALUS HOME control system
PX-BIDI, NX-BIDI
Controllers operate
at 868 MHz
UP
STOP
DOWN
PLACE FOR
A BATTERY
PX-BIDI
UP
STOP
DOWN
PLACE FOR
A BATTERY
NX-BIDI
REMOTE MANUAL
P2
(1 channel)
P2
(12 channel)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX-BIDI and is the answer not in the manual?

Questions and answers

Summary of Contents for EXALUS HOME PX-BIDI

  • Page 1 EXALUS HOME control system PX-BIDI, NX-BIDI EXALUS TR7 Spółka z ograniczoną odpowiedzialnością sp.k. Kuchary 24F REMOTE MANUAL 63-322 Gołuchów www.exalus.pl Controllers operate at 868 MHz STOP DOWN PLACE FOR A BATTERY PX-BIDI (1 channel) CHANNEL - STOP CHANNEL + DOWN...
  • Page 2 2. Use channel +/- buttons (for multi-channel devices) to select the channel number on which the device is to be programmed on the selected transmitter (PX-BIDI or NX-BIDI). 3. Press the PROG button on the EX-BIDI controller for 1 second.
  • Page 3 2. AUTOCALIBRATION OF THE EX-BIDI CONTROLLER NOTE: Before the autocalibration starts, the roller shutter drive must have pre-set end positions. If they have not been adjusted, this should be done immediately. 1. Press the P2 button on the transmitter - the roller shutter will confirm it with a short DOWN/UP movement.
  • Page 4 4. ADDING ANOTHER CHANNEL/ TRANSMITTER WITH THE EXISTING TRANSMITTER 1. Press the P2 button on the existing channel of the selected transmitter - the roller shutter will confirm it with a short DOWN/UP movement. 2. Press the P2 button again - the roller shutter will confirm it again with a short DOWN/UP movement. 3.
  • Page 5 6. PROGRAMMING OF THE INTERMEDIATE POSITION WITH PX-BIDI / NX-BIDI REMOTES: 1. Use the UP/STOP/DOWN buttons to set the roller shutter in the required intermediate position. 2. Press the STOP button for min. 5 seconds to remember the intermediate position - the roller shutter will confirm it with a short UP/DOWN movement.
