Masimo Opioid Halo Quick Start Manual

Opioid Halo™ Opioid Halo™ Opioid Halo™ Opioid Halo™ Opioid Halo™ Opioid Halo™ Opioid Halo™ Opioid Halo™ Opioid Halo™
OPIOID OVERDOSE PREVENTION
AND ALERT SYSTEM *
Quick Start Guide
Masimo Chip
- Reusable chip snaps into the sensor and
communicates with the Home Medical Hub.
Masimo Sensor
- Disposable sensor provides the monitoring
data and lasts up to 96 hours in typical
continuous usage.
- Sensor may be removed when not in use.
Be sure to remove chip between use to
preserve battery life.
1
SET UP APP & CONNECT HOME MEDICAL HUB
1. Download the app and create
an account.
Masimo HALO
2
SET UP SENSOR
1. Remove sensor from pouch.
S Y S T E M C O M P O N E N T S
2. Connect Home Medical Hub
to power.
2. Peel off yellow label to 3. Place sensor on wrist as shown and
activate battery. carefully thread the tip of the strap through
the open red loop.
© 2023 Masimo. All rights reserved.
Masimo Halo App
- Displays monitoring status.
- Cloud sends alerts to Home Medical
Hub and mobile device.
H A L O
- Compatible with most mobile devices.
(Mobile device not included.)
Home Medical Hub
- Collects data from Masimo Sensor.
- Sends data to smartphone app.
- Store the chip in the holder on top
of Home Medical Hub.
Chip Holder
Replacement Tapes
- Additional tapes for replacement
as needed.
3. Pair Home Medical Hub with phone
(Smartphone Bluetooth should be ON).
H A L O
304426/11958A-0323
4. Connect Home Medical Hub to Wifi*.
Follow step-by-step instructions on
app to set up system.
*Only compatible with 2.4 GHz wireless networks.
4. Wrap the loose end of the
strap around your wrist and
press to secure.
