ClareOne Driver / Control4 Release Notes
DOC ID - 1935, Last Modified 05/30/2023
Change Log
Revision
Date
1.0.01
5/1/2020
02
5/16/2020
03
6/18/2020
1.5.0
10/21/2020
1.5.1
11/1/2020
1.5.2
12/15/2020
1.5.3
3/18/2021
1.5.4
11/3/2021
1.5.5
1/14/2022
1.5.6
1/18/2022
1.5.7
6/08/2022
16
5/30/2023
Online Documentation
Manufacturer Website: http://www.clarecontrols.com/
Support Site: http://www.clarecontrols.com/contact
Full Documentation: http://www.clarecontrols.com/helpcenter
Introduction
ClareOne™ is the unified smart security and smart home control panel from Clare Controls. The
ClareOne Panel integrates with Control4 to add easy-to-install security features into a Control4
system. The ClareOne panel and its attached security zones auto-discover in a Control4 project,
and this driver populates a rich set of security control.
The ClareOne driver enables two-way set of security controls (arm, disarm, emergency alarm
triggering, zone status and zone bypass), and provides metadata feedback for the current panel
state (if the panel is armed, alarmed, faulted, alarmed, or in a troubled state).
Notes
•
This driver requires Control OS 3.0.0 or later to operate.
•
This driver requires that the ClareOne panel is on the same network as the Control4
system.
Installation
Only qualified installation technicians should install the ClareOne Panel and integrate it into a
Control4 system. Follow the installation and programming instructions that came with your
ClareOne equipment. Clare Controls does not assume responsibility for damages caused by
Description
Initial revision.
Bug Fixes.
Fixed binding issue.
Fixed issue where director needs
a restart after driver update.
Change name to ClareOne.
Add support for Instant Stay.
Add support for Auto Bypassing.
Add support for Secure Arming.
Bug fix for zone state not reporting to navigators.
Fixed issue with zone states on Control 4 UIs not
updating after adding new sensors.
Fixed default user code not functioning after update.
Fixed issue with zones not being removed.
Fixed issue where commands to the panel may be
delayed.
Fixed issues with Alarm Names not showing correctly,
and C4 zone chimes being disabled.
Fixed issue with disarming on entry delay.
Fixed Exit Delay time consistency when arming stay.
Fixed issue when deleting last panel zone.
Added Programming commands for Arm Auto Bypass
and Zone Bypass / Un-bypass.
Added Zone Trouble Conditions to Event History and
Fixed an issue where Trouble conditions may not show.
See the Events section for updated Events List.
Syncing up versioning to match Driver Version.
1 / 9
Advertisement
Summary of Contents for clare ClareOne CLR-C1-21
- Page 1 Full Documentation: http://www.clarecontrols.com/helpcenter Introduction ClareOne™ is the unified smart security and smart home control panel from Clare Controls. The ClareOne Panel integrates with Control4 to add easy-to-install security features into a Control4 system. The ClareOne panel and its attached security zones auto-discover in a Control4 project, and this driver populates a rich set of security control.
-
Page 2: Supported Features
Verify that the ClareOne panel is fully functional and configured before integrating with Control4. The ClareOne panel and system needs to be activated through the Clare back-end management platform, FusionPro™, to have security monitoring services enabled. All Control4 integrators authorized to sell ClareOne have been set up with FusionPro accounts. For full ClareOne panel installation and configuration, see ClareOne Wireless Security and Smart Home Panel User Manual (DOC ID 1871). - Page 3 Remote Arming / Disarming Support – With an active 4sight subscription, users can access their ClareOne system remotely. The ClareOne panel supports remote arming and disarming through Control4. The integrator has the option to disable remote disarming in Composer Pro. Security Sensor States: Sensor states can be used for Automation Events in Control4 Zone Status: Supports real-time zone status updates, even when the ClareOne panel is Disarmed.
- Page 4 Chime to take advantage of all ClareOne features below. The following feature are supported by the ClareOne panel when using T3/T4 Series Touch Screens: Chime on Entry Delay and Exit Delay To enable the delay chimes on your T3/T4 touch screen tap on your security panel device, then Settings, and select “Chime on entry/exit delay”...
- Page 5 Real time zone status Under the Zones section of the Security Partition, each Zone Name, Status and Type is displayed automatically, in real time. Arming to Away, Stay, or Instant Stay with or without a pin. When arming the ClareOne panel from a T3/T4 Touch Screen or mobile app you are presented with 3 options, Stay, Away, and Instant Stay.
- Page 6 icon on the Security Partition or entry delay countdown timer and entering a PIN code. In the event an invalid pin is used to disarm the system the Control4 UI will display “Failed to Disarm Invalid Pin” Auto Bypassing Open Zones. The ClareOne panel supports Auto Bypassing from a T3/T4 Touch Screen.
- Page 7 ▪ History Agent settings can be adjusted in Composer Pro to control how much history is shown on the touch screens and apps. Multiple Partitions A single ClareOne panel only supports a single security partition. To accomplish the effect of multiple partitions on a single project, you will need to dedicate one ClareOne panel for each partition.
- Page 8 Commands The ClareOne Driver supports commands that can be used for custom programming. ▪ Arm Auto Bypass: Allows for programming to force arming of a ClareOne pane; regardless of any open zones. Any open zones will be automatically bypassed. Supported Arm Types: ▪...
-
Page 9: Troubleshooting
Arming the panel to Instant Stay with an exit delay is not supported. The ClareOne driver does not support the addition of time in the exit delay during Arm Away. Contact Information Snap One, LLC dba Clare Controls 7525 Pennsylvania Ave, Suite 103 Sarasota, FL 34243 General: 866.424.4489...
