Summary of Contents for DNA TOOLS-00161
- Page 1 INSTRUCTION MANUAL Cordless Impact Screwdriver TOOLS-00161/00162 Power tool...
- Page 2 DESCRIPTION OF THE SYMBOLS The use of symbols in this manual is intended to draw your attention to possible risks. The safety symbols and the explanations that accompany them must be perfectly understood. The warnings in themselves do not remove the risks and cannot replace correct actions for preventing accidents.
- Page 3 GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"...
- Page 4 d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 5 eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
- Page 6 5. Forward/ reverse rotation switch TECHNICAL SPECIFIATIONS Power 12 V Speed 0-2700/min Impact rate 0-40500bpm Max. Torque 120Nm Chuck size 1/4” Noise Sound pressure level 73,2 dB(A) K=3 dB(A) Sound power level 84,2 dB(A) K=3 dB(A) Vibration level a 0,571 m/s² k= 1,5 m/s² NOISE/VIBRATION INFORMATION Measured sound values determined according to EN 62841.
- Page 7 The power voltage supply must conform to that specified on the rating plate of the rapid charger. Always inspect battery charger, cord and plug before use. Always have damage repaired by a qualified professional. Protect battery charger against humidity and operate only in dry areas. The supplied charger is suitable for charging batteries only.
- Page 8 Repair or maintenance by unqualified personnel can lead to a risk of injury. Use only identical spare parts for repairing a tool. Caution! Ensure that the batteries are charged using the correct charger recommended by the manufacturer. Attention! After long time storage, the battery capacity will be reduce. In order to maintain battery capacity, we recommend that only store full charged batteries and top-up the charge from time to time.
