10 - Your Acer Chromebook tour

Left view

(R752T)
(R752TN)
# Icon Item
1 Power button
2 Battery indicator
USB Type-C port
3
with DC-in
4 USB port
5 MicroSD card slot
Headset/speaker
6
jack
Stylus pen (select
7
products only)
1 2 3 4 5
1 2 3 4 5
6
6
Description
Turns the computer on and off.
Indicates the computer's battery
status.
Charging: The light shows amber
when the battery is charging.
Fully charged: The light shows blue
when in AC mode.
Connects to the provided USB Type-C
power adapter and to USB devices
with a USB Type-C connector.
Supports DisplayPort
Connects to USB devices.
Insert a microSD card into this slot.
Connects to audio devices
(e.g., speakers, headphones), or a
headset with microphone.
Remove the pen from the slot and
perform touch actions on the screen.
To store the pen, push it back into the
slot until you hear an audible click.
7
™ over USB-C ™ .
