- Page 1 DIGITAL ANGLE FINDER MODEL: DAF-1 Part No: 4500155 OPERATING MANUAL 11/08...
- Page 2 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
- Page 3 DIGITAL ANGLE FINDER The DAF-1 is an inovative Angle Finder with LCD display. It can be used for measuring, marking and setting angles with the following features: • Absolute and relative measurement display • Easy calibration & zero setting • Lockable blade at any angle through 360 degrees •...
- Page 4 OPERATING INSTRUCTIONS PUSH BUTTONS & LCD • Analogue quadrant indicated • High resolution 0.05 • “ABS” mode • Conversion between absolute measurement and relative measure- ment by short press • Holding • Press more than 8 seconds to turn off, short press to shut off LCD ABS SETTING In ABS mode the device will;...
- Page 5 USE OF THE SPIRIT LEVEL Plumb surface for measuring Standard level surfce USE OF THE ANALOGUE QUADRANT/MOVING BLADE...
- Page 6 DIGITAL READOUTS Both internal and external angles can be measured, the reading displayed as a positive or negative angle.
- Page 7 LOCKING POSITIONS FOR A SPECIFIC MEASURING RANGE A different measuring angle can be chosen by locking the arm at one of four different locking holes. With the arm locked precisely in position,the workpiece can be marked out accurately. REPLACING THE BATTERY Press and twist with the thumb/fingrer tips to loosen the battery cover and remove the cover.
