Lippert Unity X4 Installation Manual

Control board with bluetooth
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Lippert Connect
Unity X4
Bluetooth
™
with
Control Board
®
OEM INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Unity X4 and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert Unity X4

Summary of Contents for Lippert Unity X4

  • Page 1 Lippert Connect Unity X4 Bluetooth ™ with Control Board ® OEM INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    RGB and Dimming Lighting Control Introduction The Unity X4 Control Board can be primarily operated via the Lippert Connect app utilizing a Bluetooth connection. Users can access and adjust a system via a mobile smart device. The configurator kit supplied to OEMs must be used to program the configurable inputs and the latching and reversing outputs.

  • Page 3: Safety

    • #8 x 1" screws (4) Installation Use 4 #8 x 1" screws to secure the Unity X4 Controller in a compartment free of moisture. NOTE: Controller must be installed in a watertight location. Connect 12V power and ground to the board.
  • Page 4 Cover Screw Cover Screw Fig. 1 Cover RGB LED Inputs Low Current (LC) Reverse Polarity Outputs High Current (HC) Reverse Polarity Outputs Cover Screws Page 4 Rev: 05.06.23 CCD-0007005...
  • Page 5 NOTE: Removal of the Unity X4 controller cover is not required during installation. If needed, wiring harness connector color pin out diagrams can be found on the label (Fig. 2 and 3) on the inside of the cover (Fig. 1).
  • Page 6 NOTE: Figure 3 shows the bottom half of the pin out diagram label. Fig. 3 Page 6 Rev: 05.06.23 CCD-0007005...

  • Page 7: Wiring Connections

    II. Switch input to 10 controls RGB-2 output. CAN connections (Fig. 1E). A. The Unity X4 controller has two data cable (CAN) connection ports (Fig. 1E) that link each module in the Lippert Connect system together. Plug in the supplied 2-pin data cable (Fig. 4) to either connector and route it to the next module in the system.
  • Page 8 HVAC (Fig. 1F). NOTE: Connections are available for up to three zones of HVAC (Fig. 2). NOTE: HVAC control and monitoring through the Unity X4 controller is available only for AC units with analog controllers. A. Zone 1 (Fig. 2) is typically used as the Main Zone. It has the only HVAC zone with an output for gas heat.
  • Page 9 11. Dimming outputs (Fig. 1N). A. Dimming outputs allow for up to 8 zones of dimmable LED lighting. This is a +12V output. B. Using the DIMM OUT (Fig. 2H) pin-out diagram as a guide, make all connections for each zone used.

  • Page 10: Configuration

    Configuration Entering Configurator On the OCTP To enter SETTINGS, tap the gear icon (Fig. 6A) on the HOME screen (Fig. 6) of the OCTP. Tap SETTINGS (Fig. 7A) 5 times to access hidden settings options (Fig. 8). Tap Open Configurator > (Fig. 8A). Tap YES (Fig.

  • Page 11: Latching Relays

    Latching Relays Scroll down to the Latching Relay section and tap UNKNOWN on Latching Relay #1 (Fig. 11A). Tap Unknown under Type (Fig. 12A) and select one of the options (Fig. 13). NOTE: If more than one device type of the same name is used, press INSTANCE (Fig. 15B) to select a number, e.g.
  • Page 12 Scroll down to the next field of FUSE TYPE (Fig. 16A), select a fuse and press SET (Fig. 16B) to save the selection. Saved! (Fig. 16C) will appear in the lower left corner, replacing Loaded! NOTE: The next options are all pre-loaded but will not be active until SET is pressed and Saved! appears in the lower left corner.
  • Page 13 11. Press SET (Fig. 21A). Saved! will replace Loaded! on the screen (Fig. 22A). 12. IN-MOTION LOCKOUT LEVEL (Fig. 23): Scroll down to In-Motion Lockout Level. 13. Choose one of the options: Operation allowed or Operation NOT allowed. 14. Press SET (Fig. 24A) Saved! will replaced Loaded! on the screen (Fig. 25A). 15.
  • Page 14 18. MINIMUM OPERATING VOLTAGE (Fig. 29): Scroll down to MINIMUM OPERATING VOLTAGE. 19. Choose one of the options (Fig. 30): None, 10.0 V, 10.5 V, 11.0 V, 11.5 V, 12.0 V, 12.5 V, 13.0 V or 13.5 V. 20. Press SET (Fig. 30A). Saved! will replace Loaded! on the screen (Fig. 31A). 21.
  • Page 15 24. DSI FAULT INPUT (Fig. 35): Scroll down to DSI FAULT INPUT. 25. Choose one of the options (Fig. 36): Not Set, 1 to16. 26. Press SET (Fig. 36A). Saved! will replace Loaded! on the screen (Fig. 37A). Fig. 34 Fig.
  • Page 16 27. DEVICE ACTIVATION TIMEOUT (Fig. 38): Scroll down to DEVICE ACTIVATION TIMEOUT. 28. Choose one of the options (Fig. 39): Disabled, various increments from 1 minute to 1 hour. 29. Press SET (Fig. 39A). Saved! will replace Loaded! on the screen (Fig. 40A). 30.

  • Page 17: Reverse Polarity Outputs

    Reverse Polarity Outputs Press UNKNOWN at Momentary H-Bridge #1 (Fig. 41A) to begin programming reversing outputs. Press UNKNOWN under TYPE and select device type (Fig. 42). NOTE: If more than one device type of the same name is used, press INSTANCE (Fig. 44C) to select a number, e.g.
  • Page 18 IGNITION OPERATION MODE (Fig. 45): Scroll down to IGNITION OPERATION MODE. Choose one of the options (Fig. 46): Always or Only with ignition On. Press SET (Fig. 46A). Saved! will replace Loaded! on the screen (Fig. 47A). PARK BRAKE OPERATION MODE (Fig. 48): Scroll down to PARK BRAKE OPERATION MODE. Choose one of the options (Fig.
  • Page 19 11. IN-MOTION LOCKOUT LEVEL (Fig. 51): Scroll down to IN-MOTION LOCKOUT LEVEL. 12. Choose one of the options (Fig. 52): Operation NOT allowed or Only Retract allowed. 13. Press SET (Fig. 52A). Saved! will replace Loaded! on the screen (Fig. 53A). 14.
  • Page 20 17. EXTEND AND RETRACT INPUTS (Fig. 57): Scroll down to the EXTEND AND RETRACT INPUTS. 18. Select the input numbers to be assigned to EXTEND and RETRACT for this output (Fig. 58). 19. Press SET (Fig. 58A) Saved! will replace Loaded! on the screen (Fig. 59A) Fig.

  • Page 21: Tank Sensors

    20. Saved! will appear on the screen in the lower left (Fig. 60A). 21. Press the back button (Fig. 60B) to return to the main configuration screen. 22. Press the Home button (Fig. 60C) to return to the Home screen (Fig. 61). Fig.

  • Page 22: Hvac

    HVAC Tap UNKNOWN HVAC control (Fig. 64A) Under TYPE tap HVAC Control (Fig. 65A) to open up the selections and select the type of HVAC being named. NOTE: The default is type is HVAC Control. Under NAME tap UNKNOWN (Fig. 65B) to select the appropriate name for the HVAC Control. Tap SET (Fig.

  • Page 23: Rgb And Dimming Lighting Control

    Tap UNKNOWN Generator Genie (Fig. 64C). Under TYPE tap UNKNOWN (Fig. 68A) and change the name to Generator (Fig. 69A). Tap SET (Fig. 69B) to save the Generator Genie changes. Fig. 68 Fig. 69 RGB and Dimming Lighting Control RGB and dimming lights (Fig. 70) are latching relays and are configured the same as latching relay functions. See Latching Relay section.
  • Page 24 Any unauthorized use shall void any applicable warranty.  The information contained in this manual is subject to change without notice and at the sole discretion of Lippert.  Revised editions are available for free download from lippert.com.
