ExVection
Owner's Manual
F O R Y O U R S A F E T Y :
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other
appliance.
W A R N I N G :
Improper installation, adjustment, alteration, maintenance can cause property damage, injury, or death.
Read the installation, operating and maintenance instructions thoroughly before installing or servicing
this equipment.
Toaster must be kept free of combustible materials, and the flow of ventilation air must not be obstructed.
Operating personnel must not perform any maintenance or repair functions. Contact your Nieco Authorized
Dealer.
IMPORTANT: RETAIN THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE
Ex9225 Toaster
™
Advertisement
Table of Contents
Related Manuals for Nieco ExVection Ex9225
Summary of Contents for Nieco ExVection Ex9225
- Page 1 Toaster must be kept free of combustible materials, and the flow of ventilation air must not be obstructed. Operating personnel must not perform any maintenance or repair functions. Contact your Nieco Authorized Dealer. IMPORTANT: RETAIN THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Specifications ............12 Nieco Corporation - ExVection Toaster 9225... -
Page 3: General Information
Your Nieco ExVection™ high speed toaster features advanced technology which allows toast times unprecedented in the food service industry. ExVection™ is Nieco’s exclusive patented technology that reclaims previously wasted heat and refocuses it on the product. The result is a highly effective and efficient means of toasting product at speeds previously unheard of. -
Page 4: Site Preparation And Installation, Operating Safety
• Do not place equipment on or near a hot gas or electric burner or in a heated oven. This creates an increased risk of fire and electric shock. IMPORTANT The Nieco Corporation reserves the right to change specifications and product design. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. -
Page 5: Electrical Safety
• Do not use any accessory or attachment not recommended by Nieco. Do not operate equipment on its side or inverted. Do not introduce foreign objects into equipment. Use of equipment other than intended use could result in a hazardous situation. -
Page 6: Clearance Requirments, Operating Instructions And Settings
BUTTON 4 (----): Top Heat 0 (0%), Lower Heat 0 (0%), Speed 15 BUTTON 5 (MLT1): Top Heat 20 (100%), Lower Heat 0 (0%), Speed 5 BUTTON 6 (CLN): Top Heat 10 (50%), Lower Heat 10 (50%), Speed 15 Nieco Corporation - ExVection Toaster 9225... -
Page 7: Programming, Cleaning And Maintenence
1. Wait for toaster to cool 2. Remove the Reflector Tray and wash in sink. 3. Remove the Outlet Tray and wash in sink. 4. Clean the belt with the supplied brush. 5. Wipe the cavity of the toaster. Nieco Corporation - ExVection Toaster 9225... -
Page 8: Troubleshooting Guide, Replacing Elements, Drive Motor
3 Remove 4 motor mounting bolts and remove motor. 4. Installation is the reverse of removal. Leave the motor mounting bolts loose. 5. Adjust motor so there is 3/8” play in the chain at its widest span. tighten bolts and replace covers. Nieco Corporation - ExVection Toaster 9225... -
Page 9: Wiring Diagram
WIRING DIAGRAM Nieco Corporation - ExVection Toaster 9225... -
Page 10: Warranty
Elements replacement labor is included for 6 months, the remainder of the first year is parts only. Your warranty will begin either on the date you return the Nieco warranty card that is shipped with your machine, or 30 days after shipment of the machine from the Nieco factory. - Page 11 This is particularly true of high value important components as motors and controls, or any parts showing a pattern of failure. If required, Nieco will pay the return freight cost and give instructions via your ser- vicer on how to return the parts.
-
Page 12: Specifications
9-9-2015 Released Nieco Corporation 7950 Cameron Drive Windsor, CA 95492 (707) 284-7100 Office • (707) 284-7430 Fax www.nieco.com • e-mail: service@nieco.com Printed in the USA © 2013 Nieco Corporation All Rights Reserved P/N 99020 Nieco Corporation - ExVection Toaster 9225...
