Summary of Contents for thomann the t.bone free solo

  • Page 1 free solo Active Antenna Splitter...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 31.08.2022, ID: 314056 (V4)
  • Page 3: Table Of Contents

    Table of contents Table of contents General notes............................... 5 Safety instructions............................. 6 Features and scope of delivery......................8 Installation and starting up........................9 Connections and controls........................12 Technical specifications........................14 Protecting the environment......................16 free solo Active Antenna Splitter...
  • Page 4 free solo Active Antenna Splitter...
  • Page 5: General Notes

    General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device, include the manual for the next owner.
  • Page 6: Safety Instructions

    Safety instructions Safety instructions Intended use This device is used in wireless transmission systems to distribute and amplify the incoming antenna signals. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 7 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter ‘Technical specifications’...
  • Page 8: Features And Scope Of Delivery

    Features and scope of delivery Features and scope of delivery This appliance is used when multiple radio links are to be operated with a single antenna pair. The following features characterize the device: Amplifying the high frequency signal of a pair of antennas and distribution to 4 × 2 antenna outputs in the frequency ranges of 470 MHz to 608 MHz, 614 MHz to 694 MHz, 823 MHz to 832 MHz and 863 MHz to 865 MHz.
  • Page 9: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 10 Installation and starting up Setting up the radio connection Connect one antenna output pair of the device each to the two antenna inputs of a wireless system. To do so, use the supplied BNC cables. Connecting the power supply NOTICE! External power supply The device is powered by an external power supply.
  • Page 11 Installation and starting up Example The following illustration shows how to connect the device to the optionally available paddles and to four wireless systems. Instead of the paddles, you can also connect the device to the antennas included in the delivery. free solo Active Antenna Splitter...
  • Page 12: Connections And Controls

    Connections and controls Connections and controls Front panel ö 1 [POWER] | Main switch. Turns the device on and off. free solo Active Antenna Splitter...
  • Page 13 Connections and controls Rear panel & 2, 3 [ANTENNA-A], [ANTENNA-B] | BNC chassis connectors for cable connection to the supplied UHF omni-directional antennas. 4 Socket for connecting the supplied power adapter. 5, 6 [ANT-1] … [ANT-4] | BNC chassis connectors for cable connection to the connected wireless systems. 7 [OUTPUT1] …...
  • Page 14: Technical Specifications

    Technical specifications Technical specifications Input connections Power supply 1 × socket for connecting the plug-in power supply Antenna / booster 2 × BNC inputs (9V DC for active antennas / booster) Input impedance 50 Ω Output connections Power supply of the connected wireless 4 ×...
  • Page 15 Technical specifications Dimensions (W × H × D), without 410 mm × 45 mm × 160 mm antenna Weight 2 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20 %…80 % (non-condensing) Further information Component type Antenna splitter free solo Active Antenna Splitter...
  • Page 16: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 17 Notes free solo Active Antenna Splitter...
  • Page 18 Notes free solo Active Antenna Splitter...
  • Page 20 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
