Protegus 2

manual for GATOR gate control module

Protegus 2 v 1.20

More info @ trikdis.com

Table of Contents

Need help?

Do you have a question about the Protegus 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gator Protegus 2

Page 2: Table Of Contents
Protegus 2 manual with GATOR Content Protegus 2 v 1.20 User registration System log SMS programming 15 Add system Add system SMS control command list Add user 7 Assign PGM to user 19 Owner/Master 7 Delete user Admin Change PGM type...
Page 3: User Registration
Protegus 2 manual with GATOR User registration Protegus 2 v 1.20 You can sign in with Google account or At the entered email address you should register with email. get an email with 3 digit code. Enter those digits to confirm the email address. And press next.
Page 4 Protegus 2 manual with GATOR User registration Protegus 2 v 1.20 Enter the name by which you will be recognized by other users of the system. Registration is complete. After that, you will be transferred to the initial protegus 2 screen.
Page 5: Add System
Protegus 2 manual with GATOR Add system Protegus 2 v 1.20 To add a system, press the red plus You need to enter module IMEI or button in the initial screen. scan QR code. You can find QR con on the pack- age or module back.
Page 6: Add System
Protegus 2 manual with GATOR Add system Protegus 2 v 1.20 The module added for the first time After adding the system, a screen must be transferred to the server will open asking you to personalize closest to you. your system PGMs (outputs), or you...
Page 7: Add User
Admins can’t configure system or access advanced settings. Owner/Master The user type at Protegus 2 which are the main user on The User System, who can administrate, and configure. He can make scenarios, schedules, automation, and programming. The Only have access to control dedicated outputs.
Page 8: Add User
Protegus 2 manual with GATOR Add user Protegus 2 v 1.20 Click on the sub menu in the right Or open side menu and select corner and select “Users”. System Configuration. In the system configurations At user list press red plus button.
Page 9: Add User
Protegus 2 manual with GATOR Add user Protegus 2 v 1.20 Enter user email, name and phone Your user should be visible on the number. list. Turn on with toggle buttons the permissions you want. Assign PGM and click “Add User”.
Page 10: Schedule For Output
Protegus 2 manual with GATOR Schedule for output Protegus 2 v 1.20 In the system configurations Press “Read” button to read module choose Advanced settings. settings. Accept disclaimer. Choose IN/OUT menu item. More info @ trikdis.com ©2023...
Page 11: Schedule For Output
Protegus 2 manual with GATOR Schedule for output Protegus 2 v 1.20 Enter “Scheduler”. Set the start time by clicking on “Start time”. Choose one of the schedules. Set the time. More info @ trikdis.com ©2023...
Page 12 Protegus 2 manual with GATOR Schedule for output Protegus 2 v 1.20 Asign PGM (Output) to schedule by Go back to the main screen and pressing toggle button. press “Write” that the settings in the module would appear. Sett stop time and weeks days.
Page 13: System Log
Protegus 2 manual with GATOR System log Protegus 2 v 1.20 Enter “Advanced settings”. At the event log screen press “Read log”. Press “Read” to read module Wait for the log to be read. settings and choose “Event log”. More info @ trikdis.com...
Page 14 Protegus 2 manual with GATOR System log Protegus 2 v 1.20 Now you can inspect system log. More info @ trikdis.com ©2023...
Page 15: Sms Programming
In order to get information about You can also resset module by module. Write an SMS message sending comand “Reste (access comand to Gator. “Info (access code)”. code)”. You will get an SMS from Gator with information about module. More info @ trikdis.com ©2023...
Page 16: Sms Control Command List
Protegus 2 manual with GATOR SMS programming Protegus 2 v 1.20 SMS control command list SMS programming command list Output ON Module Info OUTPUT(number) (access code) INFO (access code) Output OFF Input status OUTPUT(number) (access code) ASKI (access code) Output Pulse (S)
Page 17 Protegus 2 manual with GATOR SMS programming Protegus 2 v 1.20 Set SMS text for event Dlete user DELU (access code) (email) TXTE (access code) N(input or output number)=(Text) DELU (access code) (tel.number) Set SMS text for event recovery Add to blacklist...
Page 18 Send UUSD code to operator (for prepaid cards) APN Password UUSD (access code) (UUSD code) CONNECT (access code) PSW=(APN password) New access code Change Protegus 2 cloud access code (access code) (new access code) CONNECT (access code) CODE=(new code) Connect to Protegus 2 CONNECT (access code) PROTEGUS=ON More info @ trikdis.com...
Page 19: Assign Pgm To User
Protegus 2 manual with GATOR Assign PGM to user Protegus 2 v 1.20 Go to side menu “Users”. In the user screen toggle PGMs that you want to assign and press “Save”. Choose the user. More info @ trikdis.com ©2023...
Page 20: Delete User
Protegus 2 manual with GATOR Delete user Protegus 2 v 1.20 Go to side menu “Users”. Press “Delete” on the top right corner. Choose the user you want to User is deleted. delete. More info @ trikdis.com ©2023...
Page 21: Change Pgm Type
Protegus 2 manual with GATOR Change PGM type Protegus 2 v 1.20 In the system configurations Choose IN/OUT menu item. choose Advanced settings. Press “Read” button to read module Choose IN/OUT menu item again. settings. More info @ trikdis.com ©2023...
Page 22 Protegus 2 manual with GATOR Change PGM type Protegus 2 v 1.20 Go to “Input/Output settings”. Press “Type”. Select the PGM you want to edit. Change the desirable PGM type. More info @ trikdis.com ©2023...
Page 23 Protegus 2 manual with GATOR Change PGM type Protegus 2 v 1.20 Go back to the main screen and press “Write” that the settings in the module would appear. More info @ trikdis.com ©2023...
Page 24: Enable/Disable Pgm
Protegus 2 manual with GATOR Enable/disable PGM Protegus 2 v 1.20 In the system configurations Choose IN/OUT menu item. choose Advanced settings. Press “Read” button to read module Choose IN/OUT menu item again. settings. More info @ trikdis.com ©2023...
Page 25: Enable/Disable Pgm
Protegus 2 manual with GATOR Enable/disable PGM Protegus 2 v 1.20 Select the PGM you want to edit. Go back to the main screen and press “Write” that the settings in the module would appear. Press “Function” button And select respectively.
