- Page 1 COOKER HOOD INSTRUCT ON MANUAL Read this manual carefully before operation Pictures in this manual are for reference only, the product in kind prevail. CHOOD90M...
-
Page 2: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS The instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATI ON The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. - Page 3 COMPONENTS Ref. Qty. Product Components Hood Body, complete with: Controls, Light, Blower, Filter. Lower Decorative Chimney Upper Decorative Chimney ( optional ) Flange ( optional ) Exhaust Pipe The Activated Charcoal filter ( optional ) Qty. Documentation Instruction Manual Ref. Qty.
- Page 4 DIMENSIONS unit：mm Min. Min. 650mm 650mm Option Chimney Height 628 / 400+0 400+300 628 670-910 628-910 400+390 628 670-1000 628-1000 728-1200 500+490 728 770-1200...
-
Page 5: Installation
INSTALLATION WALL DRILLING AND BRACKET FIXING Option Chimney 400+0 400+300 390-620 400+390 390-710 500+490 490-910 Vertical reference line As a first step, proceed with the following drawings: A vertical line up to the ceiling or up to the upper limit, at the center of the area in which the hood is to be fitted. - Page 6 Fix the brackets : Drill holes at the marked points with a ɸ10 mm drill bit. Insert the Wall Plugs 11 into the holes. Fix the hood fixing bracket 20 with 3 screws 10 (5 x 50) at the horizontal line A. ...
- Page 7 CHIMNEY ASSEMBLY Lower Decorative Chimney Fix the Lower Decorative Chimney to the hood body with 2 screws 12 (4.2 x 9.5) supplied with the hood. Upper Decorative Chimney Fix the upper chimney onto the bracket 21 with 2 screws 12 (4.2 x 9.5) supplied with the hood. ...
-
Page 8: Maintenance
MAINTENANCE GREASE FILTERS CLEANING METAL SELF-SUPPORTING GREASE FILTERS The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. Remove the filters one by one pushing them towards the back side of the hood unit and simultaneously pulling downwards. - Page 9 LIGHTING LIGHT REPLACEMENT(Completed by professionals) Replacing the light modules You cannot replaced the light bulbs, the entire light module has to be replaced. When changing the light modules, the contacts are live. Before changing the light module(s), unplug the appliance from the mains or switch off the ...
-
Page 10: Troubleshooting
TROUBLE SHOOTING Fault Cause Solution The blades are blocked. Check the blades. The capacitor is damaged. Replace capacitor. Light on, but The motor is damaged. Replace motor. motor does not The internal wiring of motor is cut off/ work Replace motor. disconnected. - Page 12 The manufacturer shall decline all responsibility if the foregoing recommendations and instruction regarding installation, maintenance and use are not observed and respected when using the cooker hood. 16173000A12802...
