Summary of Contents for BRUEL & KJAER 9640
- Page 1 Technical Documentation Turntable System Type 9640 User Manual English BE 1245 – 13...
- Page 2 Turntable System Type 9640 Consisting of: Controllable Turntable Type 5960 From serial number: 1878678 Turntable Controller Type 5997 From serial number: 1760820 Remote Control WB 1254 User Manual November 2005 BE 1245 – 13...
- Page 3 Safety Considerations This apparatus has been designed and tested in accordance with IEC 61010 – 1 and EN 61010 – 1 Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use. This manual contains information and warnings which must be fol- lowed to ensure safe operation and to retain the apparatus in safe condition.
-
Page 4: Table Of Contents
Installing National Instruments™ IEEE–488.2 Hardware and Software......11 Configuring the IEEE–488.2 for Turntable System Type 9640 ......... 11 General ..........................12 How to Use Turntable System Type 9640 for Measurements ........... 13 CHAPTER 4 Service & Repair ....................17 CHAPTER 5 The Machinery Directive .................. -
Page 6: Chapter 1 Installation
Environmental Temperature Turntable System Type 9640 will work reliably at temperatures from + 5 to + 40°C (+ 41 to + 104°F) in a relative humidity of up to 90% non-condensing at + 40°C (+104°F). The safe temperature range for storage is −25 to +70°C (−13 to +158°F). -
Page 7: Mounting
Turntable System Type 9640 – User Manual Mains Fuse Rating Ensure that the correct fuse is fitted: • 100 – 127 V: 316 mA slow-blow (T 316 mA) • 200 – 240 V: 160 mA slow-blow (T 160 mA) Use only correctly rated fuses of the specified type. Do not attempt to short-circuit the fuse holder or use “mended”... -
Page 8: Controls And Connectors
Chapter 2 Controls and Connectors Controllable Turntable Type 5960 Front Fig.2.1 Front panel of Type 5960 Motor On/Off Enables and disables rotation of the turntable without the need to switch the system off. For use when setting up the test object. Table Power For input of a power supply to the test object. -
Page 9: Rear
Turntable System Type 9640 – User Manual Rear Fig.2.2 Rear Connector of Type 5960 Connector 15-pin male connector accepting power and control signals from Turntable Controller Type 5997. Turntable Power Connector For output of a power supply to the test object. Connected to Table Power on the body of the turntable by slip rings. -
Page 10: Turntable Controller Type 5997
CHAPTER 2 Controls and Connectors Turntable Controller Type 5997 Front Panel Fig.2.3 Front panel of Type 5997 < and > Rotate the turntable clockwise and anticlockwise, respectively, or scroll through the settings available for the chosen Mode (see “Manual Use” on page 9). Mode Enters setup mode for the turntable system: Set 0°... -
Page 11: Rear Panel
Turntable System Type 9640 – User Manual Stop Stops the turntable if continuously rotating, or exits setup mode without saving the setup. Rear Panel Fig.2.4 Rear panel of Type 5997 Mains Voltage Mains Voltage selector. See section “Power Supply” on page 1. -
Page 12: Remote Control Wb 1254
CHAPTER 2 Controls and Connectors Power Mains Power Switch. Turntable 15-pin female connector providing power for and transferring control signals to Controllable Turntable Type 5960. Trig. Out 0° BNC connector for output of (positive) trigger signal as turntable passes 0° mark. Remote Control WB 1254 Fig.2.5 Remote Control WB 1254... - Page 13 Turntable System Type 9640 – User Manual Stop Stops the turntable if continuously rotating.
-
Page 14: Chapter 3 Operation
Chapter 3 Operation Manual Use Controllable Turntable Type 5960 can be manually controlled either from the front panel of Turntable Controller Type 5997 or from Remote Control WB 1254. Type 5997 allows you to set the mode of operation and to initiate rotation, while the remote control allows you to control the turntable once the mode of operation has been selected. -
Page 15: Use Of Remote Control Wb 1245
Turntable System Type 9640 – User Manual Table 3.1 Operational modes of Turntable Controller Type 5997 Mode Function Range −359° to + 359° TURN_REL When Start is pressed, the turntable will rotate by the specified angle relative to its present position. -
Page 16: Ieee Use
Installing National Instruments™ IEEE–488.2 Hardware and Software Before the IEEE interface can be used to control Turntable System Type 9640 in any applica- tion, an IEEE–488 Interface card must be properly installed in the PC that will be used to control Type 9640. -
Page 17: General
Turntable System Type 9640 – User Manual General Checking the Address Setting The IEEE address of Type 5997 (and thereby of the turntable) can be easily checked when switching it on: 1) Press and hold Start. 2) Press Power On. -
Page 18: How To Use Turntable System Type 9640 For Measurements
PULSE Electroacoustics Type 7907 or PULSE Directivity and Polar Plot BZ 5551 can be used in connection with a suitable PULSE front-end. The software packages include automated con- trol of Turntable System Type 9640 and a polar plot for displaying the directional response. - Page 19 Turntable System Type 9640 – User Manual Fig.3.2 Test setup for directional response measurements in a normal room Anechoic Room 3560 B-T63 1 0 0 M b it Brüe l & Kjær 7 /6 -'8 9 O u tp u t 1...
- Page 20 CHAPTER 3 Operation Fig.3.4 The turntable control is a powerful tool that allows the turntable to be controlled directly from the PC using an intuitive graphical user interface Fig.3.5 Polar plots are commonly used when displaying the directivity of certain electroacoustic devices such as loudspeakers and microphones...
- Page 21 Turntable System Type 9640 – User Manual...
-
Page 22: Chapter 4 Service & Repair
Chapter 4 Service & Repair Type 9640 is designed and constructed to provide you with many years of safe, trouble-free operation. However, if a fault occurs which impairs its correct function, then it must be immedi- ately switched off, disconnected from the mains supply and secured against unintended opera- tion. - Page 23 Turntable System Type 9640 – User Manual...
-
Page 24: The Machinery Directive
Chapter 5 The Machinery Directive... -
Page 25: Machinery Directive
Turntable System Type 9640 – User Manual Machinery Directive This equipment has been evaluated and found to comply with the essential safety requirements of the machinery directive (98/37/EC). The CE mark on this equipment signifies compliance with the provisions of the machin- ery directive. -
Page 26: Machinenrichtlinie
CHAPTER 5 The Machinery Directive Machinenrichtlinie Dieses Gerätesystem wurde auf Einhaltung der Maschinenrichtlinie (98/37/EG) untersucht, und die Erfüllung der grundlegenden Sicherheitsanforderungen konnte bestätigt werden. Das auf dem Gerätesystem angebrachte CE-Zeichen zeigt an, daß die Vorschriften der Maschinenrichtlinie eingehalten sind. Wir empfehlen Ihnen, die folgenden Hinweise und Warnungen zu lesen und zu befolgen. Diese Hinweise sind als Richtlinien gedacht, bei deren Anwendung außerdem gesetzliche Bestimmun- gen für Gesundheitsschutz und Sicherheit, spezielle lokale Verfahrensweisen und Sicherheits- richtlinien sowie das Bedienungshandbuch zu beachten sind. -
Page 27: Directive Sur La Sécurité Des Machines
Turntable System Type 9640 – User Manual Directive sur la sécurité des machines Cet équipement a été testé et déclaré conforme aux exigences de sécurité stipulées par la direc- tive des machines (98/37/CE). Le label CE apposé sur l’équipement indique que celui-ci est conforme aux dispositions de la directive. -
Page 28: Chapter 6 Specifications
Chapter 6 Specifications Specifications – Turntable System Type 9640 Controllable Turntable Type 5960 IEEE INTERFACE Conforms with IEEE–488.1 and compatible with Load: Max 100 kg (220 lb.) on centre, 30 kg (66 lb.) on IEC 625-1. Provides remote control of all front-panel... - Page 29 Turntable System Type 9640 – User Manual Compliance with Standards CE-mark indicates compliance with: EMC Directive, Low Voltage Directive and Machinery Directive. C-Tick mark indicates compliance with the EMC requirements of Australia and New Zealand Safety EN/IEC/UL 61010–1: Safety requirements for electrical equipment for measurement, control and laboratory use.
- Page 30 HEADQUARTERS: DK-2850 Nærum · Denmark · Telephone: +45 4580 0500 · Fax: +45 4580 1405 · www.bksv.com · info@bksv.com Australia (+61) 2 9889-8888 · Austria (+43) 1 865 74 00 · Brazil (+55)11 5188-8161 · Canada (+1) 514 695-8225 China (+86) 10 680 29906 · Czech Republic (+420) 2 6702 1100 · Finland (+358) 9-521 300 · France (+33) 1 69 90 71 00 Germany (+49) 421 17 87 0 ·...
