Armitron PRO SPORT M807 Instruction Manual

Armitron PRO SPORT M807 Instruction Manual

Advertisement

Quick Links

FEATURES

Time Telling Mode (Hours, Minutes, Seconds, Date and Day of the
Week)
Calendar Mode
24 Hour Alarm(s) with buzzer signal output
Hourly Chime: One 'Beep' sound every full Hour
Chronograph Mode: Hours, Minutes, Seconds and 11100 of a Sec-
ond with Lap Operation

Countdown Timer

Second Time Zone

Water Resistant as indicated on the watch
INSTALITE - Electro Luminescent Display

SELECTING FEATURES

1. Time Telling Mode displays Hours, Minutes, Seconds, Date, and Day of
the Week.
2. From Time Telling Mode, press 'B' once. Chronograph Mode appears.
Press 'B' four times to return to Time Telling Mode.
3. From Time Telling Mode, press 'B' twice. Alarm Mode appears. Press 'B'
three times to return to Time Telling Mode.
4. From Time Telling Mode, press 'B' three times. Countdown Timer Mode
appears. Press 'B' twice to return to Time Telling Mode.
5. From Time Telling Mode, press 'B' four times. Second Time Zone Mode
appears. Press 'B' once to return to Time Telling Mode.
6. From Time Telling Mode, press and hold 'C' Calendar Mode appears.
Release 'C' to return to Time Telling Mode.

SETTING THE TIME AND CALENDAR

1. From Time Telling Mode, press and hold 'A'. Seconds flash. Press 'C' to
zero out the Seconds.
NOTE: Zeroing out 30 or more seconds automatically adds one minute to
time.
2. Press 'B'. Hours flash. Press 'C' to advance the Hour.
NOTE: Pressing and holding 'C' will advance digits rapidly.
3. Press ' B ~ Minutes flash . Press 'C' to advance the Minutes.
4. Press 'B: Months flash. Press 'C' to advance the Month.
5. Press 'B: The Date flashes. Press 'C' to advance the Date.
6. Press 'B: The Day of the Week flashes. Press 'C' to advance the Day of
the Week
7. Press 'B'. 12 Hour or 24 Hour (Military) Time flashes. Press 'C' to select
either 12 Hour or 24 Hour (Military) Time
8. Press 'A' to end sequence and return to Time Telling Mode.

STOPWATCH

1. From Time Telling Mode, press 'B' once to enter the Stopwatch Mode.
2. Press 'C' to start timing.
3. Press 'C' again to stop timing.
4. Press 'A' to reset to zero.
5. Press 'B' to return to Time Telling Mode.

SPLIT TIME

1. While in the Stopwatch Mode, press 'C' to start timing.
2. Press 'A' to measure and display Split Time.
3. Press 'C' to stop timing at the end of the event.
4. Press 'A' to reveal the final Lap Time.
5. Press 'A' to reset to zero.
5. Press 'B' to return to Time Telling Mode.

SETTING THE 24 HOUR ALARMS

1. From Time Telling Mode, press 'B' twice to enter the Alarm Mode.
2. Press and hold 'A'. Alarm Hours flash. Press 'C' to advance the Alarm
Hour.
3. Press 'B' Alarm Minutes flash. Press 'C' to advance the Alarm Minute.
NOTE: Pressing and holding 'C' will advance digits rapidly.
4. Press 'B' Alarm Number flashes. Press 'C' to select either Alarm One (t1)
or Alarm Two (t2)
5. Press 'A' to end set sequence.
6. Press 'B' to return to Time Telling Mode.
INSTRUCTIONS MANUAL

ACTIVATING ALARM + HOURLY CHIME

1. While in Alarm Mode, press 'C' to activate the Alarm. The Alarm Symbol
appears to indicate the Alarm will sound at the preset Alarm Time for about
20 seconds or until any button is pressed.
2. Press 'C' again to activate both the Alarm and z Hourly Chime. The
Hourly Chime Symbol appears to indicate the Hourly Chime will sound
every hour on the hour.
3. Press 'C' again to deactivate the Alarm.
4. Press 'C' again to deactivate the Hourly Chime
5. Press 'B' to return to Time Telling Mode.
SECOND TIME ZONE
1. From Time Telling Mode, press 'B' four times to enter the Second Time
Zone Mode.
2. Press and hold 'A'. Hours flash. Press 'C' to advance the Hour.
3. Press 'B' Minutes flash. Press 'C' to advance the Minute.
4. Press 'A' to end set sequence.
5. Press 'B' to return to Time Telling Mode.
NOTE: The Second Time lone (Dual Time) Clock may be used to keep
track of a foreign time.

EL LIGHT FEATURE

1. Press 'D' or 'EL' in any mode to illuminate the watch face. The backlight
will remain lit for 3 seconds.
NOTE: EXCESSIVE USE OF LIGHT WILL SHORTEN BATTERY LIFE.
COUNTDOWN TIMER
1. From Time Telling Mode, press 'B' three times to enter the Timer Mode.
2. Press and hold 'A'. Hours flash. Press 'C' to advance the Hour.
3. Press 'B'. Minutes flash. Press 'C' to advance the Minutes.
4. Press 'B'. Seconds flash. Press 'C' to advance the Seconds.
5. When the Countdown Time is set, press 'A' to end set sequence and
return to Countdown Timer Mode.
6. Press 'C' to start the Countdown Timer.
7. If desired, press 'C' again to stop the Countdown Timer.
NOTE: The Countdown timing will continue in any mode until 'C' is
pressed. 11"11en the Timer has expired, the alarm will sound for about 10
seconds or until any button is pressed.
8. Press 'C' to stop the Timer.
9. Press 'B' to return to Time Telling Mode.
M807
