Philips COLOR TV 27 INCH TABLE TP2781C Quick Installation Manual

Color Television and Remote Control
A
NTENNA
O /I
UTDOOR NDOOR
A combination (outdoor
or indoor) antenna
receives normal broadcast
channels 2-13 (VHF) and
14-69 (UHF). Your con-
nection to such an antenna
is easy since there is only
one antenna plug (75Ω-
ohm) on the back of your
TV - and that's where the
antenna goes.
C TV
ABLE
C I /C
ABLE NPUT ONVERTER
Y
our Cable TV input
into your home may be
a single (75 ohm) cable, or
a Converter Box installa-
tion. In either case the
connection to the TV is
very easy. Just put the
threaded end of the cable
signal to the TV's antenna
plug and screw it down
tight.
Cable TV Converter
Box Connection
VCR TV
TO
B C
ASIC ONNECTION
T he basic Antenna, or
Cable TV, to VCR to
TV connection is shown to
the right. For more infor-
mation on other hookups
(possible when Cable
Converter/Descrambler
boxes are included) refer
to your accessory VCR
and Cable Converter
Owner's Manual for
details.
Q
How to Use the "INSTALL" Controls ..................2-3
Using the Language Control......................................2
Setting the TV to Auto Program Channels ................2
Setting the TV for a Cable or Antenna Signal...........2
Using the Adding and Deleting Channels .................3
Setting the Channel Name Control............................3
How to use the Smart Clock control .........................3
Basic TV and Remote Control Operation .................4
BEGIN
If your antenna has a
round cable connector (75
ohm) on the end, then you're
ready to connect it to the TV.
If your antenna has flat twin-
lead wire (300 ohm), you first
need to attach the antenna wires
to the screws on a 300 to 75
ohm adapter.
Combination VHF/UHF Antenna
(Outdoor or Indoor)
1
Twin Lead
Wire
BEGIN
If your Cable TV sig-
nal is a single round cable (75
ohm) then you're ready to con-
nect to the TV.
If you have a Cable TV
Converter Box:
Connect the Cable TV signal to
the Cable Signal IN(put) plug
on the Converter.
Cable TV Signal
Cable TV
Company
BEGIN
Connect your
Antenna or Cable TV signal
to the IN FROM ANT(enna)
plug on the VCR.
300 to 75Ω Ohm
Adapter
Outdoor VHF/UHF
Antenna
Cable TV signal
U
UICK SE AND
T
Getting Started
Warning/Precautions ..................................1
Hooking Up Your TV ................................1
Push the round end of the
adapter (or antenna) onto the
ANTENNA (ANT "A") plug on
the rear of the TV. If the round
end of the antenna wire is
threaded, screw it down tight.
300 to 75Ω
Adapter
(483521827003)
OR
Round Cable
75Ω Ohm
Connect the Cable TV
cable to the ANTENNA (ANT
"A") plug on the TV.
If you have a Cable TV
Converter Box:
Connect the OUT(put) plug
from the Converter to the
ANTENNA (ANT "A") plug on
the TV (connecting cable sup-
plied with the Converter.)
ANT "A"
75
OR
Round Cable
75Ω Ohm
1
Connect the OUT TO TV
plug on the VCR to the
ANTENNA (ANT "A") plug
on the TV (connecting cable
supplied with the VCR.)
1
OR
OUT TO TV
IN FROM ANT.
VCR
I
NSTALLATION
C
ABLE OF ONTENTS
• For details on product registration, warranty,
and service refer to the other literature included
with your TV information packet.
Please retain all these materials and keep them
handy for future reference.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD DO NOT EXPOSE THIS UNIT TO RAIN
OR EXCESSIVE MOISTURE.
NOTE: This Quick Use Guide may be used with
other models. Some of the features listed may or
maynot apply to your TV.
Note: For homes with separate UHF and VHF anten-
nas you will need an optional combiner to connect to
the TV.
U/V Combiner
3 0
0
OR
75-300 Ohm Adapter
2
ANT "A"
S-VIDEO
75 VIDEO
L
AUDIO
ANT "A"
75 R/MONO
IN-2
2
S-VIDEO
VIDEO
L
AUDIO
ANT "A"
75 R/MONO
IN-2 IN-1 OUT
Back of TV
Refer to the Owner's
Manual included with your
VCR for other possible con-
nections and TV/VCR operat-
ing details.
2
Round Cable
75Ω Supplied
with VCR
ANT "A"
75
Back of TV
G
UIDE
S
MART
H
ELP
Remember,
be sure to set the
TV for the type sig-
nal you've connect-
ed (see "INSTALL"
S-VIDEO
VIDEO
L
ANT "A" 75 R/MONO AUDIO
IN-2 IN-1 OUT
on page 2 of this
Back of TV
Guide.)
To order any
optional accessory
contact your dealer
or call the toll-free
accessory ordering
number:
1-800-851-8885
IN-1 OUT
Back of TV
S
MART
H
ELP
Remember,
set the TV for the
type signal you've
just connected (see
"INSTALL" page 2
of this Set-Up
Guide.)
Your TV can set
itself to select only
the channel numbers
on your Cable sys-
tem (see "AUTO
PROGRAM" page
2). If you use a
Cable Converter box,
set the TV to the
same channel as the
converter's CH 3/4
switch (on the rear of
the converter.)
S-VIDEO
VIDEO
L
ANT "A" AUDIO
75 R/MONO
IN-2 IN-1 OUT
