Summary of Contents for Prism MO10

  • Page 1 Prism Mesh Router Model: MO10 Model: MI10 User Guide v1.3...

  • Page 2: Copyright

    Prism User Guide v1.0 Dec. 2021 Copyright © 2021 BROWAN COMMUNICATIONS. This USER GUIDE is copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of BROWAN.

  • Page 3: Table Of Contents

    Prism User Guide v1.0 Dec. 2021 Contents Copyright ............................. 1 Notice ..............................1 Trademarks ............................1 CONTENTS............................. 2 ABOUT THIS GUIDE ..........................4 Purpose ............................... 4 Prerequisite Skills and Knowledge ...................... 4 Conventions Used in this Document ....................4 CHAPTER 1 – INTRODUCTION ......................5 Configuration............................
  • Page 4 Tools > Device discovery ....................... 38 Tools > Speedtest .......................... 39 CHAPTER 8 - APPENDIX ........................40 I/O Description, Wall Mount, and Basic Installation of MO10 ............40 I/O Description, Wall Mount, and Basic Installation of MI10 ............42 FCC/IC Statement ......................... 44...

  • Page 5: About This Guide

    Prism User Guide v1.0 Dec. 2021 About this Guide Purpose This document provides information of web configuration of the Prism Mesh Access Points: - MI10 - MO10 Prerequisite Skills and Knowledge To use this document effectively, you should have a working knowledge of Local Area Networking (LAN) concepts and wireless Internet access infrastructures.

  • Page 6: Chapter 1 - Introduction

    Chapter 1 – Introduction Thank you for choosing the Prism Mesh Access Point product. The Prism Mesh Access Point product features 2.4GHz+5GHz 2x2 and 5GHz 4x4 tri-band with a superior connectivity capability across large-range density deployments such as office spaces, training and meeting facilities, shopping mall and hotel.
  • Page 7 Prism User Guide v1.0 Dec. 2021 You can choose to click Skip or enter a new password then click Save to proceed: Page 6 of 51...

  • Page 8: Chapter 2 - Web Menu

    Dec. 2021 Chapter 2 – Web Menu This chapter describes the configuration menu page of the Prism Mesh Access Point which works in AP mode, Station mode or Mesh mode by using the Web Interface configuration. The default configuration is AP mode.
  • Page 9 Prism User Guide v1.0 Dec. 2021 DPI graphs – show user’s traffic and application information Settings Network – specify the network parameters Wireless – specify the settings of Wi-Fi radios Services – specify management’s interfaces System – configure basic access point’s information Users –...

  • Page 10: Chapter 3 - Dashboard

    Prism User Guide v1.0 Dec. 2021 Chapter 3 - Dashboard This chapter describes the dashboard page of the Prism Mesh Access Point. Dashboard > Site The Site page shows important information of system and network status. Device information – display the access point’s basic information System resources –...

  • Page 11: Dashboard > Network

    Prism User Guide v1.0 Dec. 2021 Dashboard > Network The Network page shows the status of the network Local Network – display the IP information of network interface of the access point ARP entries – show all IP and MAC information of the whole network DHCP active leases –...

  • Page 12: Dashboard > Interfaces

    Ethernet 0 (LAN2) Ethernet 1 (LAN1) Ethernet 2 (WAN) For MO10, there is only one Ethernet port: Ethernet 0 (water-proof Ethernet port) Wireless Radios – display the status of each radio, including channel, bandwidth, Tx power, connected clients (users) and SSID information Please follow country-specific regulation.

  • Page 13: Dashboard > Clients

    Prism User Guide v1.0 Dec. 2021 Dashboard > Clients The Clients page shows the status of connected clients (wireless users) information. Wireless clients – show the connected clients (wireless users) information, including MAC, Radio, SSID, Security and Uptime Backhaul – show the connected mesh clients information, including MAC, Radio, SSID, Security and Uptime Clients information –...

  • Page 14: Dashboard > Activity

    Prism User Guide v1.0 Dec. 2021 Dashboard > Activity The Activity page shows the event log related to the access point. Event log data is downloadable by clicking Download data button. Page 13 of 51...

  • Page 15: Chapter 4 - Mesh

    Dec. 2021 Chapter 4 - Mesh This chapter describes the mesh configuration of the Prism Mesh Access Point. Central Aceess Point (CAP) is the Root (also known as Master) of mesh network that provides Internet connectivty to whole mesh network.

  • Page 16: Mesh > Mesh Wizard

    Prism User Guide v1.0 Dec. 2021 Mesh > Mesh Wizard The Mesh Wizard page will guide you to establish mesh network step by step. Mesh > Mesh Wizard (Create a CAP) Step 1 To create a CAP, select Central Access Point (CAP) from Mesh Configuration, then click Next.
  • Page 17 Prism User Guide v1.0 Dec. 2021 Alias and Location can be kept blank. Step 3 Enter Backhaul SSID and Backhaul passphrase, then click Next. Backhaul SSID – an unique ID for establishing wireless mesh connection Backhaul passphrase – password for wireless mesh connection 1.

  • Page 18: Mesh > Mesh Wizard (Add A Re)

    Prism User Guide v1.0 Dec. 2021 Mode – specify the security mode from menu, including Open, WPA2 personal, WPA2 enterprise and WPA3 enterprise Passphrase – specify the password of the WiFi SSID 1. WiFi name (SSID), Security Mode and Passphrase, are used for stations (users) to connect.

  • Page 19: Mesh > Mesh Information

    Prism User Guide v1.0 Dec. 2021 Alias and Location can be kept blank. Step 3 Enter Network ID, then click Finish. Network ID – an unique ID for adding RE into existing mesh connection Please note that RE’s Network ID should be the same as CAP’s.

  • Page 20: Mesh > Mesh Information

    Prism User Guide v1.0 Dec. 2021 Mesh > Mesh Information Mesh topology is shown here. Settings > Wireless > Networks Once mesh configuration is enabled, go to Settings > Wireless > Networks for detailed settings. Page 19 of 51...
  • Page 21 Prism User Guide v1.0 Dec. 2021 The following describes the default settings of Central Access Point (CAP). Network zone – Local Network in default To know more about Network zone, please refer Settings > Network > Zones. In CAP mode, the DHCP client is enabled in Local Network configuration, and DHCP server is enabled as well.
  • Page 22 Connect (WPS push) – force to send the Network ID manually Resync – force to send the CAP’s RF configuration to RE Select Network AP (Prism) – once mesh is configured as CAP, the other two radio interfaces will be changed to Access Point mode automatically SSID –...
  • Page 23 Prism User Guide v1.0 Dec. 2021 The following describes the default settings of Range Extender (RE). Network zone – Local Network in default To know more about Network zone, please refer Settings > Network > Zones. In RE mode, the DHCP client is enabled in Local Network configuration, but DHCP server is disabled.
  • Page 24 Prism User Guide v1.0 Dec. 2021 Select Network AP (Prism) – once mesh is configured as RE, one radio is configured to mesh connection and the other two radio interfaces will be changed to Access Point mode automatically SSID – the name of Access Point Network zone –...

  • Page 25: Chapter 5 - Dpi

    Prism User Guide v1.0 Dec. 2021 Chapter 5 - DPI DPI > DPI graphs DPI will be available in future release. Page 24 of 51...

  • Page 26: Chapter 6 - Settings

    Prism User Guide v1.0 Dec. 2021 Chapter 6 - Settings This chapter describes the settings of the Prism Mesh Access Point. Settings > Network > Zones There are two default configurations for interface type in network zones, Internet for WAN type and Local Network for LAN type.

  • Page 27: Settings > Network > Ethernet

    Prism User Guide v1.0 Dec. 2021 IPv4 netmask - enter the defined netmask DHCP broadcast – enable to broadcasting DHCP dicovery message Custom DNS – a DNS server can be specified Custom MAC – the MAC address of physical Ethernet port can be changed to meet network setting Local Network configuration in default is defined as a fixed IP and DHCP server is enabled.

  • Page 28: Settings > Network > Static Routes

    Prism User Guide v1.0 Dec. 2021 MO10 has only one physical port - Ethernet 0. MI10 has three physical ports - Ethernet 0, Ethernet 1 and Ethernet 2. Settings > Network > Static routes Static routes allow you to manually adding routing rules to remote networks in table.
  • Page 29 Prism User Guide v1.0 Dec. 2021 Mesh configuration – disable in default Suggest to configure mesh connection by using Mesh Wizard. Please refer to Chapter 4 when mesh configuration is enabled. Mode – The mode can be selected to Access Point or Station mode Access Point Mode SSID –...

  • Page 30: Settings > Wireless > Radios

    Prism User Guide v1.0 Dec. 2021 Maximum 8 SSIDs can be added and configured. Station Mode Enable on radio – select the radio to work as station SSID – Clicking Scan to do the site survey and select the Wi-Fi network the station would like to connect.
  • Page 31 Prism User Guide v1.0 Dec. 2021 5 GHz Radio (5G-1) – Wi-Fi 5GHz 2x2 radio, normally as Access Point 2.4 GHz Radio – Wi-Fi 2.4GHz 2x2 radio, normally as Access Point 5 GHz Radio (5G-2) – Wi-Fi 5GHz 4x4 radio, dedicated backhaul radio once mesh is enabled Enable –...

  • Page 32: Settings > Services

    Prism User Guide v1.0 Dec. 2021 Channel width – 4 channel width parameters can be chosen from drop-down menu 20MHz, 40MHz , 80MHz or 160MHz, depending on radio capability Channel – Auto in default. Channel can be selected from drop-down menu Tx power (dBm) –...

  • Page 33: Settings > Services > Ssh

    Prism User Guide v1.0 Dec. 2021 Settings > Services > SSH It allows you to enable SSH port for accessing the mesh access point. Settings > Services > Telnet It allows you to enable Telnet for accessing the mesh access point.

  • Page 34: Settings > Services > Device Discovery

    Prism User Guide v1.0 Dec. 2021 Settings > Services > Device discovery This feature allows to find other devices, as well as to broadcast information to other devices, in the same network. Settings > Services > SNMP It allows you to enable SNMP to be managed by a network management system (NMS).

  • Page 35: Settings > Services > Snmp Traps

    Prism User Guide v1.0 Dec. 2021 Settings > Services > SNMP Traps The SNMP trap is a type of SNMP protocol, that sends an unrequested message to the manager to notify about an important event. Settings > Services > Remote syslog By enabling this function, syslog will be stored in a file or sent a remote logging server.

  • Page 36: Settings > Services > Prismx Agent

    Prism User Guide v1.0 Dec. 2021 Settings > Services > PrismX Agent By enabling PrismX Agent and input the server IP address of PrismX Controller, the device would be added to the PrismX Controller control list. Settings > System This page allows you to configure system-related settings.

  • Page 37: Settings > Users

    Prism User Guide v1.0 Dec. 2021 Example firmwares.json: "mango": { "checksum": "0675d2cd94a1af66c3fa0a3553ab5bee", "image": "Mango_zefir-master-cc99739-7773762.bin", "version": { "firmux": "7773762", "release": "1.9.0", "sdk": "cc99739" Other settings – Physical reset button can be enabled/disabled Settings > Users This function allows you to change the username or reset the password, and to add new credentials.

  • Page 38: Chapter 7 - Tools

    Prism User Guide v1.0 Dec. 2021 Chapter 7 - Tools This chapter describes the utility functions of the Prism Mesh Access Point. Tools > Site survey This function allows you to perform site survey per radio to understand the usage of other Wi-Fi networks in the environment.

  • Page 39: Tools > Traceroute

    Prism User Guide v1.0 Dec. 2021 Tools > Traceroute The Traceroute is a utility that uses ICMP packets to record the route through the internet from one computer/server to another. Tools > View log It shows you the real-time system log.

  • Page 40: Tools > Speedtest

    Prism User Guide v1.0 Dec. 2021 Tools > Speedtest It helps to check upload and download speeds of the mesh access point. Page 39 of 51...

  • Page 41: Chapter 8 - Appendix

    Prism User Guide v1.0 Dec. 2021 Chapter 8 - Appendix I/O Description, Wall Mount, and Basic Installation of MO10 Page 40 of 51...
  • Page 42 Prism User Guide v1.0 Dec. 2021 Page 41 of 51...

  • Page 43: I/O Description, Wall Mount, And Basic Installation Of Mi10

    Prism User Guide v1.0 Dec. 2021 I/O Description, Wall Mount, and Basic Installation of MI10 Page 42 of 51...
  • Page 44 Prism User Guide v1.0 Dec. 2021 Page 43 of 51...

  • Page 45: Fcc/Ic Statement

    Prism User Guide v1.0 Dec. 2021 FCC/IC Statement MO10 Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 46 (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This radio transmitter [IC: 26296-MO10] has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated.
  • Page 47 Prism User Guide v1.0 Dec. 2021 Caution: the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; Avertissement: les dispositifs fonctionnant dans la bande de 5150 à 5250MHz sont réservés uniquement pour une utilisation à...
  • Page 48 Prism User Guide v1.0 Dec. 2021 Professional installation instruction (MO10) Please be advised that due to the unique function supplied by this product, the device is intended for use with our interactive entertainment software and licensed third-party only. The product will be distributed through controlled distribution channel and installed by trained professional and will not be sold directly to the general public through retail store.
  • Page 49 Prism User Guide v1.0 Dec. 2021 Instructions d'installation professionnelle (MO10) Veuillez noter que l'appareil etant dedie a une fonction unique, il doit etre utilise avec notre logiciel proprietaire de divertissement interactif . Ce produit sera propose par un reseau de distribution controle et installe par des professionels;...
  • Page 50 Prism User Guide v1.0 Dec. 2021 MI10 Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 51 Prism User Guide v1.0 Dec. 2021 Industry Canada statement: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference...
