- Page 1 ORIGINAL INSTRUCTIONS>EN JIG SAW RACSS650 USER GUIDE CAUTION: Read this manual before use this machine!
-
Page 2: Table Of Contents
CONTENTS 1. INTENDED USE 2. SAFETY INSTRUCTIONS 3. YOUR PRODUCT 4. OPERATION 5. CLEANING AND MAINTENANCE 6. TECHNICAL DETAILS 7. DISPOSAL 8. DECLARATION OF CONFORMITY 9. WARRANTY 10. PRODUCT FAILURE 11. WARRANTY EXCLUSIONS... -
Page 3: Intended Use
1. INTENDED USE The power tool is intended for sawing wood, metal and plastics. Not suitable for professional use. 2. WARNING INSTRUCTIONS 2.1 GENERAL POWER TOOL SAFETY INFORMATION WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. - Page 4 h. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second. 4) Power tool use and care Do not force the power tool.
- Page 5 Be careful when working on walls. Damage to power supply lines, gas or water pipes can lead to dangerous situations. Use appropriate detectors to establish whether there are concealed wires or pipes in the working area. Secure the work piece. The work piece is only secure if it is held by work-holding devices or in a vice. ...
-
Page 6: Your Product
3. YOUR PRODUCT 1. Speed selector 6. Pendulum adjustment knob 11. Butterfly nut for parallel guide 2. On/off button 7. Baseplate 12. Protective guard 3. Lock button 8. Parallel guide 13. Adaptor for dust extraction 4. Cable 9. Press roller 5. - Page 7 5.2 ADJUSTING THE BASEPLATE The baseplate (7) can be adjusted to 45 in relation to the saw direction to allow bevelling. Use the Allen key(5) to loosen the two screws under the baseplate, adjust the plate to the desired angle and then retighten the screws.
- Page 8 5.4 ADJUSTING THE PENDULUM REGULATOR The saw’s pendulum (counterweight) has four settings which can be selected using the pendulum adjustment knob (6). These settings can be used to adjust the travel and quality of the cut to the type of material to be sawn.
-
Page 9: Cleaning And Maintenance
5.6 SAWING WOOD • Check that the item does not contain nails or other metal objects. Always wear a mask. 5.7 SAWING METAL • We recommend lubricating the material and saw blade with cutting oil to protect the tool and avoid overheating. -
Page 10: Declaration Of Conformity
32, rue Aristide Bergès - ZI 31270 Cugnaux - France, declares that, Product: Jigsaw Model: RACSS650 Serial number:20230208013-20230209212 is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration. -
Page 11: Warranty
9. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 12: Product Failure
10. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one . b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 13: Warranty Exclusions
11. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 14 NOTES...
- Page 15 NOTES...
- Page 16 BUILDER SAS 32, rue Aristide Bergè s - ZI 31270 Cugnaux - France MADE IN PRC 2023...
