SUBMERSIBLE MOTORS 4" Encapsulated - BF Motor REWINDABLE MOTOR 6" Water Filler with PE2/PA - BF Motor REWINDABLE MOTOR 8" Water Filler with PE2/PA - BF Motor REWINDABLE MOTOR 10" Water Filler with PE2/PA - BF Motor INSTALLATION MANUAL CHOICE OF CABLES www.britefil.com... -
Page 4: Submersible Motors 3" - Bf Motor
• Suitable for horizontal operation. Motor range versions • Single Phase: 0,37kW (0,5hp) to 0,75kW (1hp), 220- 230V/50Hz (ou 60Hz) • Three Phase: 0,37kW (0,5hp) to 1,10kW (1,5hp), 380- 415V/50Hz - 460V/60Hz. • Other voltage and frequencies available upon request. www.britefil.com... - Page 5 • Voltage variation: +/- 10%. • Single phase motor available with permanent split capacitor. • Suitable for horizontal operation. Motor range versions • Single Phase: 0,37kW (0,5hp) to 0,75kW (1hp), 220- 230V/50Hz (ou 60Hz) • Other voltage and frequencies available upon request. www.britefil.com...
-
Page 6: Submersible Motors 4" Rewindable Oil Filled - Bf Motor
• Axial Thrust: - 1500 N from 0,37kW to 2,2kW - 2500 N from 2,2kW to 5,5kW - 5000 N from 2,2kW to 5,5kW - 7500 N from 2,2kW to 7,5kW. • Other voltage and frequencies available upon request. www.britefil.com... -
Page 7: Submersible Motors 6" Rewindable Oil Filled - Bf Motor
230V/50Hz (or 60Hz) • Three Phase: 4kW (5,5hp) to 37kW (50hp), 380- 415V/50Hz - 460V/60 Hz • Axial Thrust: - 10.000 N from 4kW to 22kW - 20.000 N from 30kW to 37kW. • Other voltage and frequencies available upon request. www.britefil.com... -
Page 8: Submersible Motors 4" Encapsulated - Bf Motor
415V/50Hz - 460V/60 Hz • Axial Thrust: - 1500 N from 0,387 kW to 0,75 kW - 3000 N from 1,1 kW to 2,2 kW -+ 6500 N to 3kW to 7,5 kW. • Other voltage and frequencies available upon request. www.britefil.com... -
Page 9: Rewindable Motor 6" Water Filler With Pe2/Pa - Bf Motor
• Availability to be operated by Soft-Starter • Rewindable BF Motors (PVC, PP & PE2+PA winding wire) provides long service life." Options • Cable Length • Pt100 temperature sensor • Hot water applications • Materialinox304 - 316 • Starting DOL or Y/ www.britefil.com... -
Page 10: Rewindable Motor 8" Water Filler With Pe2/Pa - Bf Motor
• Availability to be operated by Soft-Starter • Rewindable BF Motors (PVC, PP & PE2+PA winding wire) provides long service life." Options • Cable Length • Pt100 temperature sensor • Hot water applications • Materialinox304 - 316 • Starting DOL or Y/ www.britefil.com... -
Page 11: Rewindable Motor 10" Water Filler With Pe2/Pa - Bf Motor
• Availability to be operated by Soft-Starter • Rewindable BF Motors (PVC, PP & PE2+PA winding wire) provides long service life." Options • Cable Length • Pt100 temperature sensor • Hot water applications • Materialinox304 - 316 • Starting DOL or Y/ www.britefil.com... -
Page 12: Installation Manual
Any improper use of the motor may cause damage to the motor and to the plant; and invalidates product warranty. Instructions and prescriptions refer to the standard installation: for any special arrangement please contact Britefil Technical Department. BF MOTOR DESCRIPTION Stator impregnated with a special epoxy resin and hermetically sealed, in order to guarantee the best electrical insulation and the most efficient cooling. - Page 13 Maximum immersion depth: 350 m Voltage tolerance: ± 10% Vertical or horizontal use is allowed. If the motor is combined with a frequency converter, please contact Britefil Technical Department. Remind that in case of using the motor in aggressive environments, any anomaly or malfunction are under the responsability of the installator.
- Page 14 Fuses and overload protections are recommended in order to keep the motor safe. For further information, please contact Britefil Technical Department. A high sensitivity circuit breaker device is recommended. Motor has to be earthed according to local regulation! CAUSES OF FAILURES OR MALFUNCTIONS No power supply.
-
