U2A's inputs. It should be –10dBV device. The numbers on
the bottom show the relative levels in dB.
2. GANG MODE
Links the L-R faders for stereo operation. Un-select the Gang
Mode if you need to control the left and right levels
independently.
Select the input source type for audio recording.
1. ANALOG IN
Selects the analog input port ( -10dBV unbalanced) on the
U2A as the USB wave input source.
2. DIGITAL IN
Selects the digital input port (SPDI/F Coaxial or Optical) on
the U2A as the USB wave input source.
Select the input connector type for your digital audio input.
1. COAXIAL
Selects the Coaxial input port (RCA type S/PDIF format) on
the U2A as the digital input source.
2. OPTICAL
Selects the Optical input port (Toslink, S/PDIF format) on the
U2A as the digital input source.
Clock Source determines that U2A will reference to. Clock Source is
the time reference that determines precisely where each digital audio
sample begins and ends. Also, Clock Source in U2A control panel
U S B W A V E I N
D I G I T A L I N
C L O C K S O U R C E
1 6
S E L E C T
S E L E C T
