3 Button Remote Security System

FEATURES:

2 Three Button Programmable RF Transmitters

Three Channel Receiver (capable of accepting 4 transmitters)

Code Hopping Technology

Remote Panic in all modes

Protected Valet

7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming

Intrusion Alert with Memory

Audible Arm / Disarm / Defective Zone / Tamper Confirmation

Instant Siren Activation

Low Current Horn Output

Starter Disable

True Last Door Arming (hardwire only)

Defective Zone By-Pass

Hardwire or Voltage Sense Selectable

Active or Passive Arming Selectable

Programmable Auto Lock On / Off

Programmable Auto Unlock On / Off

Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L

Programmable Active or Passive Door Locks

User Programmable Permanent Chirp Delete

On Command RF Chirp Delete from Transmitter

6 Tone Multi-Tone Siren

RF Inhibit with ignition on

Parking Light Flasher

OPTIONS:

Single or Dual Stage Shock Sensor

Remote Trunk Release

Remote Keyless Entry

Multiple Vehicle Capable

Remote Starter

Remote Power Window Roll Up

Remote Garage Door Interface

From 9642a with new transmitters & PBLED 5/07

Model PRO-9642a

Owner's Manual

Page 1

128-8179

1 of 8

Table of Contents

Need help?

Do you have a question about the PRO-9642a and is the answer not in the manual?

Questions and answers

Summary of Contents for PURSUIT PRO-9642a

Page 1 Model PRO-9642a Owner's Manual 3 Button Remote Security System FEATURES: 2 Three Button Programmable RF Transmitters Three Channel Receiver (capable of accepting 4 transmitters) Code Hopping Technology Remote Panic in all modes Protected Valet 7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming...
Page 2 NOTE: Your system has the option of using a siren, the vehicle horn, or both for the sounding device. Where the siren is referenced below, the horn or both may in fact chirp, or beep. ARMING THE SYSTEM - ACTIVE 1.
Page 3 PROTECTION WHILE THE SYSTEM IS ARMED Opening any protected door, hood, or trunk lid will cause the alarm to immediately sound. The alarm will continue to sound for 30 seconds, then stop and continue to monitor all protected entry points. If the thief left a door opened, the alarm will sound for six 30 second cycles, remain armed and ignore that triggered zone.
Page 4 If the parking lights flashed three times, then the alarm was triggered in your absence. Before turning the key on, examine the LED to identify which zone was triggered. Siren/Horn does not sound. If the siren and or horn sounds 4 chirps, then the alarm was triggered in your absence.
Page 5 MANUALLY OVERRIDING YOUR SYSTEM: USING THE PBLED OVERRIDE SWITCH Your Security System can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to operate your vehicle if the transmitter is lost or its battery fails.
Page 6 5. Within 10 seconds, begin to press and release the PBLED switch to set the tenths digit. (As per the example, press and release 5 times to set the tenths digit to 5) 6. Within 10 seconds of the last press of the pushbutton, turn the ignition switch off then on. 7.
Page 7 2. To stop the alarm, press and hold the Lock or Unlock button on the transmitter again for 3 seconds. If the button is not pressed, the alarm will automatically stop after 30 seconds. Also if any transmitter button other than the Lock or Unlock button is pressed and released, the Panic mode will be turned off immediately.
Page 8 PRO-9642a SYSTEM FUNCTIONS AT A GLANCE DASH LED INDICATORS RAPID FLASHING PASSIVE ARMING SLOW FLASHING = ARMED DISARMED ON SOLID VALET MODE 3 FLASH...PAUSE = INTRUSION ZONE 3 2 FLASH...PAUSE = INTRUSION ZONE 2 1 FLASH...PAUSE = INTRUSION ZONE 1...
