3B SCIENTIFIC ® PHYSICS
Remote-Controlled Positioning System PS 400
Instruction Manual
03/23 TL
1 Connection socket for sliding rail (12)
2 Display
3 Keys step size for moving steps (mm)
4 Connection for AC power supply
5 Voltage output V
out
6 Function keys
7 2 x ground socket
(230 V, 50/60 Hz) 1023414
(115 V, 50/60 Hz) 1023791
1
8 Interface for CMA-sensors
9 Sliding rail
10 Step motor
11 Transport belt
12 Connection cable for control unit (1)
13 Sled, mounting assembly
14 Screw for clutch force
15 Lock for mounting assembly (13)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Advertisement
Table of Contents
Summary of Contents for 3B SCIENTIFIC PHYSICS PS 400
- Page 1 3B SCIENTIFIC ® PHYSICS Remote-Controlled Positioning System PS 400 (230 V, 50/60 Hz) 1023414 (115 V, 50/60 Hz) 1023791 Instruction Manual 03/23 TL 1 Connection socket for sliding rail (12) 8 Interface for CMA-sensors 2 Display 9 Sliding rail 3 Keys step size for moving steps (mm)
- Page 2 The movement of the sled is uniform: v = con- stant. The Remote-Controlled Positioning System PS 400 enables fast and exactly reproducible Precision of moved distance: ± 0.1 % positioning of components in experiments. Fixed and programmable positioning steps with...
- Page 3 The "home" position is changed when the 6. Disposal sled collides with components or hits the end of the carriageway. The "home" posi- The packaging should be tion should be reset afterwards. disposed of at local recy- The sled moves away from the motor by cling points.
