Installation Manual.
Universal Elite Multi-Lingual LCD Terminal
IMPORTANT NOTE: This product, if running V8.0 firmware or later, provides configuration
options that also allow installation in Concept 1000/2000 systems (Aust & NZ only). If
installing in a Concept 1000/2000 system, you will require the Concept 1000/2000 Supplement
to this manual. P/N: 635000MLC2K. This can be downloaded from the Inner Range Website:
http://www.onlinetraining.innerrange.com/login/index.php
Elite LCD Terminals are used to perform programming and User operations, display alarm messages
and review system activity. A backlit keypad allows for positive PIN & data entry and indicator LEDs
provide Area/system status information. The module number and options are programmed from the
keypad. Flush/surface mount options, Tamper monitoring, Zone Inputs and Auxiliaries are provided.
This Multi-Lingual version also provides support for multiple charactor sets and allows the Installer to
choose the character set that matches the Language provided in the Control Module firmware.
NOTE: An option for simple PIN, ON and PIN, OFF Area control is now provided via LCD Terminals.
See the Programming Manual V7.8 or later for details.
Elite LCD Terminal Parts List
- Elite LCD Terminal assembly.
- Alternative rear casing.
- Alternative hinged front cover.
- 4 x M2.5 Self tapping screws.
(2 for fixing front of case to rear, +
2 spare)
- Installation Manual and mounting
template. (This document)
LAN Wiring
The LAN is connected using twisted pair
communications cable. Connect Data A & B
using one pair; POS & GND with another pair.
Data A & B must be on the same pair.
(Over longer distances, use heavy duty Fig.
8 for POS & GND, or a separate power
supply) Cabling distance should be no more
than 1.5km from the Control Module or a
LAN Isolator, "LAN 2 or 3" Port.
Zone Inputs
Tnn:Z01 Zone Input 1. Connect Door Reed if
Door Forced/DOTL required. (No EOL required)
Tnn:Z02 Zone Input 2. Connect REX button
if required. (No EOL required)
See Programmer's manual for details of LCD
Terminal System Inputs.
NOTE: Tnn = Terminal Number.
Universal Elite Multi-Lingual LCD Terminal. Rev 2.0 June 2011
Specifications
Power Supply Input:
Operational Current:
Auxiliary Output Current:
Physical dimensions:
Installation environment:
Terminal powered
11V to 14V DC
Normal: 20mA.
100mA max. Each.
Height:
Width:
Depth:
0º - 40º C @15% to 85% Rel.
humidity (non-condensing)
B A GND POS X1 X2 X3 X4
* LAN POS not
connected if
from external
Power supply.
B A - +
From
Previous
module
Auxiliaries
T??:X01 Aux. 1.
T??:X02 Aux. 2. or LED 4. (See page 4)
T??:X03 Aux. 3 unless used for Zone 1
T??:X04 Aux. 4 unless used for Zone 2
or Pulse Beeper option.
T??:X05 Aux. 5. Internal Beeper.
T??:X06 Aux. 6. LED 1.
T??:X07 Aux. 7. LED 2.
T??:X08 Aux. 8. LED 3.
995000ML
Max: 45mA
143mm,
89mm,
28mm
*
B A - +
To next
module
