Pass through Connector for the Digital I/O Signals
Compatible with the Analog Discovery 2 and Analog Discovery (Legacy)

Compatible Products

The Analog Discovery Audio Adapter is compatible with the following:
Analog Discovery 2
Analog Discovery (Legacy)
About this Document
This reference manual applies to Revision B of the Analog Discovery Audio Adapter.

Functional Description

Connectors and Jumpers

Label Name
J1 2×15 Analog
Discovery
connector
J2 2×15 Analog
Discovery
connector
J3 Mono/Stereo Jack
connector
J4 Mono Jack
connector
JP1 Mono/Stereo
Selection Jumper

Visualizing the Audio Signals

The Analog Discovery Audio Adapter is used to analyze the audio signals taken from an
external source or from the Analog Discovery. It uses the Oscilloscope device
instrument. If the audio signals are generated by the Analog Discovery, a 3.5mm male
jack stereo cable needs to be connected to the stereo input of the audio adapter. The
Interfaces the Audio Adapter with the Analog Discovery
Used for passing through the unused signals of the
Analog Discovery
Used to connect a mono or a stereo audio source to
the inputs of the Analog Discovery scope
Used to connect a mono audio source to the inputs of
the Analog Discovery scope
Used to select if through J3 will pass a mono or stereo
signal
Description
