Summary of Contents for Intelligent Appliance IA-2662-E
- Page 1 User Manual IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range Version 0614 www.intelligent-appliance.com...
- Page 2 30VDC / TTL / LVTTL I/O Range Copyright Copyright © 1985-2014 Intelligent Appliance Ltd. All rights reserved. The information in this user manual is subject to change without notice. Microsoft, Windows and Hyper-Terminal are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
-
Page 3: Table Of Contents
Jumper Settings ..............................9 Digital Input / Output Terminal Block ......................... 10 ............................... 11 NTERNAL IRCUITS IA-2662-E(N/T/R) , Digital Inputs ........................11 IA-2662-EN, Open Collector 300mA Sink ......................12 IA-2662-ET, TTL Output ............................13 IA-2662-ER, Resistor Output ..........................13 COMMAND SET..............................14 0 –... -
Page 4: Introduction
Input protection circuits enable secure operation on wide voltage range of over +/- 30Volts. The IA-2662-E internal circuits may be operated on 5V supply or 3.3V supply in order to best fit customer’s needs. Both supplies are on board, ready to run. -
Page 5: Specifications
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range Specifications Communication Port COM version Isolated TCP/IP COM Speed 10/100 base-T Default IP 10.1.1.22 Default port Digital Output Channels Rated Current ‘N’ Suffix: -300mA ‘T’ Suffix: +/-24mA ‘R’... -
Page 6: Ordering Information
30VDC / TTL / LVTTL I/O Range Output Current: Resistor Limited Warning & Safety Intelligent Appliance products are NOT authorized for use as components in life support devices or systems. Do not operate the device in a manner not specified in the documentation. Misuse of the device may result in injury and/or damage equipment. -
Page 7: Installation
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range Installation System Wiring Host PC RJ45 RJ45 www.intelligent-appliance.com Specifications are subject to change without notice... -
Page 8: Pin Assignment
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range Pin Assignment J1 – Main Port (RJ45) TB1, TB2, TB3 - Digital input signals TB4, TB5, TB6 - Digital Output signals TB7 – Power Supply and Relay... -
Page 9: Jumper Settings
Jumper #4 - 5V/3.3V – Operation Voltage Selector This Jumper affects both Input and Output Voltage! This Jumper should be set while No Power is applied to the IA-2662-E Module! www.intelligent-appliance.com Specifications are subject to change without notice... -
Page 10: Digital Input / Output Terminal Block
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range Digital Input / Output Terminal Block Digital Input Digital Output TB1-Upper TB6-Lower Digital Input Digital Output TB1-Lower TB6-Upper Digital Input Digital Output TB2-Upper TB5-Lower Digital Input Digital Output... -
Page 11: Internal Circuits
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range Internal Circuits IA-2662-E(N/T/R) , Digital Inputs Ei(1,2,3) Ext. Source +5V +3.3V (1,2,3) Digital Input www.intelligent-appliance.com Specifications are subject to change without notice... -
Page 12: Ia-2662-En, Open Collector 300Ma Sink
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range The IA-2662-E module includes 3 different product versions. Each product version includes a different Digital Output Stage. IA-2662-EN, Open Collector 300mA Sink Common Positive Digital Output The IA-2662-EN includes a Darlington Open Collector output stage with a maximum Sink Current of 300mA per a single channel and 100mA for all 8 channels at 100% duty cycle. -
Page 13: Ia-2662-Et, Ttl Output
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range IA-2662-ET, TTL Output +5V +3.3V Digital Output The IA-2662-ET includes a TTL output stage with a current Sink/Source capacity of +/-24mA. Total Sink current is limited to 1Amp. Total Source current is limited to 0.25Amp. -
Page 14: Command Set
30VDC / TTL / LVTTL I/O Range Command Set The following table is a quick reference table for the IA-2662-E, A host computer / PLC may control the IA-2662-E by simply sending ASCII commands though a standard COM port. Each command is structured from a delimiter character, modules address, command character, data if any, carriage returns character. -
Page 15: Aa0 - Get Device Name
Command: ?010<CR> Response: _2662<CR> Request the device at address 01Hex to send its model name. The response indicates that the command was successful and that the device at this address is IA-2662-E www.intelligent-appliance.com Specifications are subject to change without notice... -
Page 16: Aa1 - Get Device Firmware Version
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range ?aa1 – Get device firmware version Description Request the Device version Syntax ?aa1<CR> Delimiter character Hexadecimal address of the device Get device Version command <CR> Carriage Return - End of command Response _nnnn<CR>... -
Page 17: Aa2 - Get Digital Output Status
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range ?aa2 – Get Digital output status Description Read Digital outputs present status Syntax ?aa2<CR> Delimiter character Hexadecimal address of the device Read outputs status <CR> Carriage Return - End of command Response _ABCDEFGHIJKLMNOP<CR>... -
Page 18: Aa5 - Get Device Mode
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range ?aa5 – Get Device mode Description This command reads the module operation mode Syntax ?aa5<CR> Delimiter character Hexadecimal address of the device System Mode command <CR> Carriage Return - End of command Response _dd<CR>... -
Page 19: Aai - Get Digital Inputs Status
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range ?aaI – Get Digital inputs status Description Read Digital inputs present status Syntax ?aa2<CR> Delimiter character Hexadecimal address of the device Read inputs status <CR> Carriage Return - End of command Response _ABCDEFGHIJKLMNOP<CR>... -
Page 20: Aaid - Get Module's Id Number
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range ?aaID – Get module’s ID number Description This command reads the Device ID Syntax ?aaID<CR> Delimiter character Hexadecimal address of the device Command for read ID <CR> Carriage Return - End of command... -
Page 21: Aas - Get Jumper & Led Status
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range ?aaS – Get jumper & led status Description This command reads the status of JP1 and the LED. Syntax ?aaS<CR> Delimiter character Hexadecimal address of the device Read jumper &... -
Page 22: Aa2Dddddddddddd - Set Relay Status
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aa2dddddddddddd – Set relay status Description This command defines module’s output state. Syntax !aa2dddddddddddd <CR> Delimiter character Hexadecimal address of the device System control command Digital output activation command data for each nibble in hex format <CR>... -
Page 23: Aa3Dd - Activate Relay N
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aa3dd – Activate relay N Description This command activates a single relay. Syntax !aa3dd <CR> Delimiter character Hexadecimal address of the device Single relay activation command N Relay ID in hex format <CR>... -
Page 24: Aa4Dd - De Activate Relay N
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aa4dd – De activate relay N Description This command De activates a single relay. Syntax !aa4dd <CR> Delimiter character Hexadecimal address of the device De activate relay N command N Relay ID in hex format <CR>... -
Page 25: Aa5Dd - Set Device Mode
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aa5dd – Set device mode Description This command sets the power-up mode and enables/disables error messages. Syntax !aa5dd <CR> Delimiter character Hexadecimal address of the device System mode command... -
Page 26: Aa6Dd - Set Baud Rate
96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aa6dd – Set baud rate Description For compatibility with existing devices the IA-2662-E can be set to other standard baud rates Syntax !aa6dd <CR> Delimiter character Hexadecimal address of the device... -
Page 27: Aa 7 Dd - Set Module ' S Address
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aa7dd – Set module’s address Description Each device must have a unique network address. This command defines a module’s address. Syntax !aa7dd <CR> Delimiter character Hexadecimal address of the device... -
Page 28: Aasdd - Set User Defined Led
IA-2662-E 96-ch digital I/O TCP/IP Controlled 30VDC / TTL / LVTTL I/O Range !aaSdd – Set user defined led Description This command turns ON or turns OFF the SLD LED Relay operation will be operational in PCB v.12. Syntax !aaSdd <CR>...
