deltalight WALKER 55 LED WW Installation Instructions

Installation instruction

WALKER 55 LED WW
6 220 55 4102
= A / G
150mm
5"-15/16
WALKER 53 LED WW
6 220 53 4102
= A / G
150mm
5"-15/16
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
50mm
2"

Application

Floor surface mounted
For indoor & outdoor use
533mm
21"

Color Finish

A - Alu gray
G - Grey brown

Light source

1 x POWERLED WHITE 7W / 3000K

Product description

Powder coated corrosion protected aluminum housing
Electronic power supply included. 120V input, 350 mA current controlled class 2 output.
5' SJ00W cable included
Suitable for wet locations
Dust-protected
Protected against water jets
Walker 55: Weight: 6,4lbs 2,9kg
Walker 53: Weight: 3,3lbs 1,5kg
Accessories not supplied (Option)
6 216 12 00
229 01 12
229 02 07
50mm
2"
263mm
10"-3/8
NORTH AMERICAN EDITION
IP55
JUNCTION BOX
PIN 12
PLATE 7
WALKER 55 LED WW
WALKER 53 LED WW
V02
Conforms to ANSI/UL Std. 1598
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update 22/11/2013
1
