Paramont PAR-ALLBIRA650DN Quick Start Manual

Analog High Definition 4 IN 1 IR Camera
ITEM №:
PAR-ALLBIRA650DN

Caution for Installation

1. In order to prevent electronic shock, don't loosen any screws or covers.
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. Don't operate the camera beyond its temperature, power source
ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.

Packing

1. Camera
2. User Manual
3. Screw
4. Plastic-Conical-Anchor
5. Hexagonal Wrench
6. Mounting drawing paper
7. Video Line
8. Base plug
X1
X1
X4
X4
X1
X1
X1
X1

Specification

ITEM
IP Rating
Type
Signal System
Pick Up Device
Picture Elements
Min Illumination
S/N Ratio
Lens
3D
WDR
OSD
Video Out-put
Power Supply
Current Consumption
IR Effect Distance
Dimension
Weight
Storage Temperature
Operating Temperature
Remark: Non-regulative adaptor may cause camera damaged.
PAR-ALLBIRA650DN
IP67
Removable IR Cut Filter
NTSC/PAL
1/2.8" 5M SONY CMOS
2688 (H)X1944 (V)
0Lux（12Pieces IR LED ON）
≥56B
6-50mm Motorized Varifocal Fixed Iris Lens
ON
ON/OFF
YES
HD-AHD/HD-TVI/HD-CVI/CVBS
DC12V ±10%/AC24V±10%
DC12V:1400mA(MAX)/AC24V:400mA(MAX)
110m（360.6ft）
268.5×110.8X106mm (10.57"×4.36" ×4.17" )
1290g
-30～+60℃ (-22～+140℉)
-30～+50℃ (-22～+122℉)
