DeVilbiss Air Power Company STEEL DRIVER Series Operation, Maintenance And Parts Manual

Stick framing nailer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

DeVILBISS AIR POWER COMPANY

Operation, Maintenance, and Parts Manual for SFN6

STICK FRAMING NAILER

MODEL ........................................................... SFN6

AIR INLET........................................................ 1/4" NPT

WEIGHT .......................................................... 7 lbs. 6 ozs.

LENGTH .......................................................... 22.8"

HEIGHT ........................................................... 15.2"

MAXIMUM PRESSURE .................................. 125 PSI

PRESSURE RANGE......................................... 80-115 PSI

FASTENER LENGTHS .................................... 2" - 3 1/2"

MAGAZINE CAPACITY .................................. 75-105 Nails

SCFM REQUIRED @ 90 PSI ........................... Every 10 Fasteners

MINIMUM COMPRESSOR HP

REQUIRED TO OPERATE ............................... 3/4 HP

This manual contains information that is important for you to know and understand.

This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT

PROBLEMS. PLEASE READ THIS MANUAL.

MGP-SFN6-1

7/15/97

STEEL DRIVER SERIES

Specifications

DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615

Delivered Per Minute

Requires .95 SCFM

(TANK MOUNTED)

Table of Contents

Need help?

Do you have a question about the STEEL DRIVER Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DeVilbiss Air Power Company STEEL DRIVER Series

Page 1 This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. PLEASE READ THIS MANUAL. DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615 MGP-SFN6-1 7/15/97...
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE Tool Specifications ..................Front Cover Table of Contents ......................2 Limited Warranty ......................3 Safety Guidelines ......................4 Warning Chart ......................4-6 Lubrication and Maintenance ..................7-8 Recommended Hook-up ....................8 Contact Trip Safety Mechanism ..................9 A.
Page 3: Limited Warranty
ONE YEAR FROM DATE OF PURCHASE All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and generators used in consumer applications (i.e., personal residential household usage only).
Page 4: Safety Guidelines
SAFETY GUIDELINES This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, use the following symbols. Please read the manual and pay attention to these sections. URGENT SAFETY INFORMATION.
Page 5 SAFETY GUIDELINES DANGER Read these warnings carefully. Failure to follow warnings will result in severe injury or death! Risk of head injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN HOW TO PREVENT IT Metal fragments, fasteners, or other ma- Always wear ANSI approved Z87 safety njury to eyes, head and hearing terial could be projected against head or glasses, Z89.1 head protection and...
Page 6 SAFETY GUIDELINES Risk of puncture injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN HOW TO PREVENT IT Connecting and Disconnecting Accidental discharge of a fastener can Hold tool by the handle and keep trigger Air Hose occur. and contact trip safety mechanism from contacting objects or parts of the body when connecting or disconnecting air supply.
Page 7: Lubrication And Maintenance
LUBRICATION AND MAINTENANCE NOTE Many air tool users find it convenient to use an Oiler to help provide oil circulation through tool. An Oiler also increases the efficiency and useful life of the tool. An oiler is recommended for tools that receive heavy or constant use.
Page 8: Recommended Hook-Up
LUBRICATION AND MAINTENANCE Always connect the Female Quick Coupler to the air hose. Do not use any type of flammable gases or oxygen as a Never connect the Female Quick Coupler to the tool. power source for the tool. Use filtered, lubricated, regu- lated compressed air only.
Page 9: Contact Trip Safety Mechanism
CONTACT TRIP SAFETY MECHANISM The trigger is released after each fastener is driven. Move the tool to the next desired fastener location and repeat the procedure above. CHECKING THE OPERATION OF Never keep the trigger pulled on contact trip tools CONTACT TRIP SAFETY MECHANISM when carrying or holding the tool.
Page 10: Loading The Tool
LOADING THE TOOL Disconnect tool from air supply before adjusting, Handle the tool carefully, respect the tool as a working clearing jams, servicing, relocating and during non- implement and always assume the tool contains operation. fasteners: a. Never use the tool as a toy and engage in horse- play.
Page 11: Clearing A Jam From The Tool
OPERATING THE TOOL 1. Add a drop of DeVilbiss DV1719-01 Air Tool Oil, high 4. Test for proper fastener penetration by driving fasteners speed spindle oil, such as Unocal RX22, or 3-in1 oil into a sample piece of wood. If the fasteners do not into the air inlet.
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Stop using the Tool immediately if any of the following occur. Serious personal injury could occur. Warranty repairs or replacements must be performed by a DeVilbiss Air Power Authorized Service Center Only. PROBLEM CAUSE SOLUTION Seals in trigger valve housing are damaged. Air leaking at trigger valve area.
Page 13: Exploded View
EXPLODED VIEW...
Page 14: Parts List
PARTS LIST PART PART DESCRIPTION DESCRIPTION NSP-185 SET SCREW NSP-224 PILOT VALVE NSP-186 DUST CAP ----- O-RING NSP-187 HEX HEAD BOLT ----- SPRING NSP-188 CYLINDER CAP NSP-227 TRIGGER VALVE STEM * 5. ----- CAP SEAL ----- O-RING NSP-190 PISTON STOP NSP-229 INNER VALVE SEAT * 7.
Page 15: Fasteners
FASTENERS Crown Shank Shank Fastener Penny Head Type Length Gauge Type Collation Finish Part # 2 3/8" .113" Smooth Clipped Paper Tape Bright/Coated 6FSN57-1 2,000 3" .121" Smooth Clipped Paper Tape Bright/Coated 6FSN70-1 2,000 Clipped 3" .131" Smooth Paper Tape Bright/Coated 6FSN71-1 2,000...
Page 16 WARRANTY This product is covered by the DeVilbiss one year limited warranty. The warranty can be found on page 3 or is available upon request. DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615...
