DuraTrel 11116 Assembly Instructions Manual

General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Two 7/16" wrenches or sockets
... Tape Measure
... File
with #2 phillips bit, ¼", ⅛" drill bits
8' Picnic Table
11116
Model#
Part #
1 1½ x 5½ x 96" Table Rail
2 1½ x 5½ x 96" Table Rail
3 1½ x 5½ x 96" Seat Rail
4 1½ x 5½ x 59½" Cross Brace
5 1½ x 5½ x 30¼" Leg
6 25½" Table Bracket
7 8¾" Seat Bracket
8 ⅞ x 1½ x 27" Center Brace
9 ⅞ x 1½ x 33¾" Diagonal Brace
10 28" Table End Cap
11 11 ⅛" Seat End Cap
12 6 ⅛" Leg End Cap
13 5½" Cross Brace End Cap
14 Hardware Bag
⅞ x 1½" End Cap
¾" Painted Screw
1 ½" Painted Screw
¼ x 3½" Bolt
¼ x 2¼" Bolt
¼" Nylock Nut
¼" Flat Washer
Super Glue Tube
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description Box#
1
(with wood)
1
2
(with wood)
1
2
(with wood)
2
2
2
2
2
2
2
2
2
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
3
2
4
2
4
2
4
1
2
2
4
4
4
1
2
72
12
8
18
26
52
2
1
