Summary of Contents for Real Spirit Advanced Pure Air H2O
- Page 1 Atmospheric Water Generator Owner’s Manual Produced and distributed exclusively by: V. 001...
- Page 2 Before First Use Leave the Atmospheric Water Generator (AWG) standing upright and outside of the box for at least 24 hours before plugging it in. The AWG may have been tilted or placed upside down during shipping. Leave the AWG standing upright for at least 24 hours so the oil in the compressor can settle from shipping.
-
Page 3: Table Of Contents
Table of Contents Safety Information & Precautions ....1 How It Works ....... .3 Parts Identification . -
Page 4: Safety Information & Precautions
Do not share the electrical outlet with other appliances. • Always use replacement and maintenance parts supplied by Real Spirit USA/H2O Machine. Failure to do so will void the warranty. • Insert the three-prong plug on the power cord into a matching electrically grounded outlet (110-120V/60 Hz, 15A at least). - Page 5 Safety Information & Precautions • The AWG is not to be used or intended to be used by person (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision, or instruction by an adult or person responsible for their safety.
-
Page 6: How It Works
How it Works An atmospheric water generator (AWG) is a device that extracts water from humid ambient air. Simply put, the AWG captures and filters humid air around you bringing it to its dew point. The water is then collected and filtered again to create safe, healthy, filtered alkaline drinking water virtually anywhere. -
Page 7: Parts Identification
Parts Identification Front Back 1.Water Storage Tank 2 Harvester 2 Harvester 1. Water Storage Tank 7. Water Collector Tank 13. Wifi 2. Harvester 8. Water Out (Optional) 14. Operation 3. Chrome Faucet 9. Water In 15. Full 4. Water Drip Tray 10. -
Page 8: Operating Instructions & Setup
Operating Instructions & Setup Step 1 Unpack your atmospheric water generator (AWG) and carefully remove all the tape and cardboard used in shipping. Inside the dispenser (water storage tank) box you will find tubing, an Interface Cable, and water drip tray. Note: Find a flat, leveled location out of direct elements, like sun and rain. - Page 9 Operating Instructions & Setup Step 5 Take the small white plastic tubing and connect the top (IN) and the bottom box. Push the plastic tubing in about a 1/4 of an inch. Replace the blue clip to secure the tubing in place. Next connect the interface cable to the Storage Tank and Water Generator unit.
-
Page 10: Operating & Setup Notes
Operating & Setup Notes • When turned on the compressor will activate in a few minutes, if your humidity is above 30-40% you will start creating water. You should see water production within 48-72 hours. Do not turn off or unplug the unit during this time. •... -
Page 11: Maintenance
Maintenance Ensure the Atmospheric Water Generator (AWG) is turned OFF and the plug is removed from the power socket before performing cleaning or maintenance. Replacing the Filters The AWG creates purified great tasting water from the air by following the recommended filter replacement schedule. Filter 01-05 replace every 12 months or 4000L (Roughly every 1,000 gallons) Replace the pre-filter with every filter 01-05 replacement, or when... -
Page 12: Cleaning The Awg
Maintenance Cleaning the AWG Be sure to unplug the AWG from the wall outlet before starting any cleaning processes. Clean the AWG housing with a soft damp cloth. Do not submerge or place water on the AWG. Water may damage the electrical components of the AWG. -
Page 13: Replacing The Charcoal Mesh Pre-Filter
Maintenance (cont.) Cleaning the charcoal mesh pre-filter (cont.) 3. Follow the steps below to clean the filter. A. Use a vacuum cleaner to remove dirt from the surface of the filter, or rinse the filter with warm water and mild detergent and place it in a cool place to dry thoroughly. -
Page 14: Winterizing The Awg
Maintenance (cont.) When not using the AWG for more than 4 weeks & Winterizing 1. Unplug the AWG from the wall. 2. Drain your tanks and lines by opening the chrome faucet (which will be left open during storage) allowing the water to dispense. -
Page 15: Frequently Asked Questions
Frequently Asked Questions Product Information Will it overflow when its full? No, the H2O Machine will shut down when the water storage tank is full. Does this use UV light? No, the H2O Machine does not have UV or UVC lights. Is this reverse osmosis? No, reverse osmosis wastes, and creates unhealthy acidic water. - Page 16 Frequently Asked Questions (cont.) Product Information (cont.) create water. The system needs 48 hours to cycle and communicate. Is the machine heavy? We recommend a two person lift whenever moving the H2O Machine around. What is this black button? It’s a reset button. Rarely used to reset the on board circuit board while not restarting the compressor.
-
Page 17: Warranty
Whether in the first 5 years or subsequently, upon discovery of a product defect, you should immediately notify Real Spirit USA, Inc via telephone or email of the exact problem you are having to the best of your knowledge. - Page 18 Water Damage Liability Statement and Waiver Real Spirit USA, Inc accepts no liability, nor offers any warranty or remedy for damages of any kind in regard to water damage caused or reported to be caused by leaks from hoses, fittings, or directly from any of our products.
-
Page 19: Product Specifications
Product Specifications Product Name Atmospheric Water Generator Model/Part Number APA-H2OAWG-001 Power Usage 110-120V/60 Hz. Wattage: 1000W Max. 7.8 Amps. 836W Dimensions Combined: 14.5” W x 16.5” D x 42.5” H Water Storage Tank: 14.5” W x 16.5” D x 15” H Harvester: 14.5”... - Page 20 Scan the QR Code with your Smart Phone Camera or Visit: https://bit.ly/3yQlKX5 Advanced Pure Air and H2O Machine™ are trademarks of Real Spirit USA, Inc. ® The exclusive technologies used by the H2O Machine are protected by International and U.S. Patents registered with the USPTO.
