- Page 1 Instructions for installation and operation Compressed air refrigeration dryer DRS30-DRS125 EN - English...
- Page 2 Dear customer, Thank you for deciding in favour of the DRS30-DRS125 compressed-air refrigeration dryer. Please read these installation and operating instructions carefully before mounting and starting up the DRS30-DRS125 and follow our directions. Perfect functioning of the DRS30-DRS125 and thus reliable compressed-air drying can only be guaranteed when the provisions and notes stipulated here are strictly adhered to.
-
Page 3: Table Of Contents
13.2 Dryer dimensions DRS 60-80 13.3 Dryer dimensions DRS 100 13.4 Dryer dimensions DRS 125 13.5 Exploded diagrams 13.5.1 Components of the exploded diagrams 13.5.2 Exploded diagram DRS 30-80 13.5.3 Exploded diagram DRS 100 13.5.4 Exploded diagram DRS 125 DRS30-DRS125... - Page 4 13.6 Electric diagrams Electric diagrams – list of components 13.6.1 13.6.2 Electric diagram DRS 30-100 13.6.3 Electric diagram DRS 125 0\mod_ Pos : 1 /Beko Tec hnisc he Dok um entati on/Ü bersc hriften/1/Sic herheits hinw eise @ DRS30-DRS125...
-
Page 5: Name Plate
/ certified skilled personnel prior to installation, start-up and maintenance. The operating instructions must be accessible at all times at the place of application of the DRS30-DRS125 compressed-air refrigeration dryer. -
Page 6: Safety Pictograms In Accordance With Din 4844
Qualified and authorised operators are persons who are instructed by the manufacturer regarding the handling of the refrigeration system, with experience and technical training, and who are well-grounded in the respective provisions and laws. DRS30-DRS125... - Page 7 • CFC-free refrigerants • CFC-free insulation material • Energy-saving design • Limited acoustic emissions • Dryer and packaging comprise reusable materials This symbol advises the user to observe the environmental aspects and comply with the recommendations connected with this symbol. DRS30-DRS125...
-
Page 8: Signal Words In Accordance With Ansi
Installation works must exclusively be carried out by authorised and qualified skilled personnel. Prior to undertaking any measures on the DRS30-DRS125 compressed-air refrigeration dryer, the certified skilled personnel shall read up on the device by carefully studying the operating instructions. The operator is responsible for the adherence to these provisions. - Page 9 Refrigerant leak! A refrigerant leak involves the danger of serious injury and damage to the environment. The DRS30-DRS125 compressed-air refrigeration dryer contains fluorinated greenhouse gas/refrigerant. Installation, repair and maintenance works at the refrigeration system must only be carried out by certified skilled personnel (specialists).
-
Page 10: Proper Use
When delivered, the dryer is tested and fully assembled. The customer only needs to connect the device to the system in accordance with the instructions in the following chapters. Pos : 15 /Bek o T ec hnis che D ok umentati on/Übesc hriften/1/Aussc hluss v om Anw endungs bereic h @ 0 \mod_1236003439359_6.doc @ 13709 DRS30-DRS125... -
Page 11: Exclusion From A Field Of Application
The maximum operating pressure indicated by the manufacturer on the name plate must not be exceeded. It is the installer's responsibility to install the appropriate safety and control devices. Prior to the start-up of the DRS30- DRS125 compressed-air refrigeration dryer, the connected pressure generator (compressor etc.) must be set to the max. -
Page 12: Storage
Allow a sufficient clearance on each side of the dryer for proper ventilation and to facilitate maintenance operations. The dryer does not require attachment to the floor surface. Do not obstruct the ventilation grille (not even partially). Prevent any recirculation of the outgoing cooling air. Protect the dryer against draughts. DRS30-DRS125... -
Page 13: Installation Plan
Note! Contaminated intake air! In the event that the intake air is strongly contaminated (ISO 8573.1 class 3.-3 or poorer quality), we recommend the additional installation of a prefilter (5 micron minimum), to avoid clogging of the heat exchanger. DRS30-DRS125... -
Page 14: Correction Factors
Minimum std. air flow rate = = 43 scfm (73 m³/h) 1.00 x 0.93 x 1.00 Therefore the model suitable for the conditions above is DRS 60 (60 scfm [102 m³/h] - nominal duty). DRS30-DRS125... -
Page 15: Connection To The Compressed-Air System
Supply voltage and missing earth connection! Important: ensure that the plant is connected to earth. Do not use plug adapters at the power plug. Possible replacement of the power plug must only be carried out by a qualified electrician. DRS30-DRS125... -
Page 16: Condensate Drain
During the installation and operation of this device, all national regulations regarding electronics and any other federal and state ordinances, as well as local provisions, need to be adhered to. The operator and the user must ensure that the dryer is not operated without panels. DRS30-DRS125... -
Page 17: Initial Start-Up
(flow-rate, temperature of the incoming air, ambient temperature, etc.) During the operation, the refrigerating compressor runs continuously. The dryer needs to be switched on during the entire compressed-air usage time, even if the compressed-air compressor works periodically. DRS30-DRS125... -
Page 18: Shut Down And Restart
The dryer must not be started up more than six times an hour. Wait at least five minutes prior to every restart. The user is responsible for the compliance with these provisions. Irreparable damage can be caused when starting up the device too often. DRS30-DRS125... -
Page 19: Technical Data
Technical data 10 Technical data DRS30-DRS125... -
Page 20: Technical Description
The low-pressure gas is resupplied to the compressor, where it is compressed again. It then re-enters the cycle. In phases of a reduced compressed-air load, the excess refrigerant is resupplied automatically to the compressor via the hot gas bypass valve. DRS30-DRS125... -
Page 21: Flow Chart
Condensate drain service valve Not installed Condensate drain strainer Not installed Condensate drain solenoid valve Compressor Coil for condensate drain solenoid valve Hot gas by-pass valve Electronic instrument Condenser Pressure transducer BP2 Condenser fan Compressed air flow direction Refrigerant gas flow direction DRS30-DRS125... -
Page 22: Refrigerating Compressor
Without compressed air flow through the dryer, rotate the adjusting screw (position A on the drawing) until the following value is reached: Hot gas setting : R134.a pressure 29.0 psig (+ 1.45 / -0 psi) [2.0 barg (+0.1 / -0 bar)] DRS30-DRS125... -
Page 23: Electronic Instrument Dmc35
1st (left) and 10th (right) led Failure BT1 (DewPoint) temperature probe. are flashing Failure BT2/BP2 (fan control) probe. and led are flashing NOTE : fan is forced always ON. DewPoint too low and display 1st (left) led are flashing (lower than -1°C / 30°F). DRS30-DRS125... -
Page 24: How Is Controlled The Condenser Fan
NOTE : parameter values are displayed on the 10 led display where 1st (left) led is the lowest limit and 10th (right) is the highest limit. NOTE (1): T set at the 10 led (right) keep drain output always powered and led always off (used if electronic drainer is installed) DRS30-DRS125... -
Page 25: Maintenance, Troubleshooting, Spare Parts And Dismantling
Certified skilled personnel Installation works must exclusively be carried out by authorised and qualified skilled personnel. Prior to undertaking any measures on the DRS30-DRS125 compressed-air refrigeration dryer, the certified skilled personnel shall read up on the device by carefully studying the operating instructions. The operator is responsible for the adherence to these provisions. -
Page 26: Troubleshooting
Installation works must exclusively be carried out by authorised and qualified skilled personnel. Prior to undertaking any measures on the DRS30-DRS125 compressed-air refrigeration dryer, the certified skilled personnel shall read up on the device by carefully studying the operating instructions. The operator is responsible for the adherence to these provisions. - Page 27 LED of DMC35 electronic instrument is flashing - see specific point. Ambient temperature is too low - restore nominal conditions. The hot gas by-pass valve is out of setting - contact a refrigeration engineer to restore nominal setting. DRS30-DRS125...
- Page 28 1st (left) led are flashing ◆ DMC35 DewPoint too high - see specific point. The BT1 DewPoint probe is faulty - replace it. Display 10th (right) The electronic instrument is faulty - replace it. led is flashing DRS30-DRS125...
-
Page 29: Recommended Spare Parts
In case of failure of other parts, for example inside the refrigerating circuit, the replacement must be worked out by a refrigerating systems specialist or in our factory. NOTE: To order the suggested spare parts or any other part, it’s necessary to quote the data reported on the identification plate. DRS30-DRS125... -
Page 30: Maintenance Works At The Refrigeration Cycle
Caution! Refrigerant! Maintenance and repair works at refrigeration systems must only be carried out by KAISHAN service technicians in accordance with the local provisions. The total amount of refrigerant in the system must be collected for recycling purposes, resource recovery or disposal. -
Page 31: Appendices
Appendices 13 Appendices 13.1 Dryer dimensions DRS 30-40 DRS30-DRS125... - Page 32 Appendices 13.2 Dryer dimensions DRS 60-80 DRS30-DRS125...
-
Page 33: Dryer Dimensions Drs 100
Appendices 13.3 Dryer dimensions DRS 100 DRS30-DRS125... -
Page 34: Dryer Dimensions Drs 125
Appendices 13.4 Dryer dimensions DRS 125 DRS30-DRS125... -
Page 35: Exploded Diagrams
56 Base plate 11 Capillary tube 57 Upper plate 12 T1 temperature probe (dew point) 58 Carrier support 13 Condensate drain service valve 59 Support bracket 14 Condensate drain strainer 61 Electric connecting plug 15 Condensate drain solenoid valve DRS30-DRS125... -
Page 36: Exploded Diagram Drs
Appendices 13.5.2 Exploded diagram DRS 30-80 DRS30-DRS125... -
Page 37: Exploded Diagram Drs 100
Appendices 13.5.3 Exploded diagram DRS 100 DRS30-DRS125... -
Page 38: Exploded Diagram Drs 125
Appendices 13.5.4 Exploded diagram DRS 125 DRS30-DRS125... - Page 39 Only air-cooled Check the transformer connections with regard to the supply voltage Jump, if not installed Provided and cabled by the customer Internal control Time-controlled drain outlet (not used) Only water-cooled BROWN ORANGE BLUE BLACK WHITE YELLOW/GREEN WH/BK WHITE/BLACK DRS30-DRS125...
- Page 40 Appendices 13.6.2 Electric diagram DRS 30-100 DRS30-DRS125...
- Page 41 Appendices 13.6.3 Electric diagram DRS 125 DRS30-DRS125...
- Page 44 Contact Information __________________________________________________________ Kaishan, USA LLC 15445 Industrial Park Dr, Loxely, AL, 36551 251.257.0586 www.KaishanUSA.com 74MD0021C0-EN_00...
