- Page 1 Baikal miner GIANT USER’S GUIDE http://www.baikalminer.com...
- Page 2 Start Giant Installation guide...
- Page 3 Giant Specifications Input Power 12V/5A DC Interface Operation Temp 0 ~ 40 ℃ Dimension 300mm(L) x 123mm(W) x 123mm(H) Weight 2550g Power Algorithm Hash Rate Power Efficiency (at the wall, with 25℃ ambient temp) 900MH/s±10% 217W±5% 0.25J/MH 900MH/s±10% 255W±5% 0.29J/MH...
-
Page 4: Package Contents
Package Contents 1 Giant Miner 1 4-pin USB cable 1 dual row 5-pin cable *Note* 12V DC ATX Power Supply is not pakage contained but required for the installation. Connection Guide Select any one of 2 boards and connect it to Orange Pi with 4-pin USB cable. - Page 5 <Connection guide for 6-pin power cable> Connect Ethernet port on Orange Pi to Ethernet. Power the ATX power supply on *Note* Setting Giant miners in daisy-chain 4 Giants at maximum Only 1 Orange Pi and Ethernet connection are required for ...
-
Page 6: Pool Setting
Pool setting Enter Giant IP address on your web browser to access pool setting page and log in with ‘baikal’ as password. (IP address can be found either on setting page of your internet router or by using our program from download link) First page you’d see if you log in successfully. - Page 7 1 – Pool links for your information 2 – Server URLs from each pools 3 – Select Algorithm type 4 – Your wallet address 5 – Pool password (normally set as x) 6 – Give priority with your own numbers; the system counts lowest number as first and the next as second regardless how big are the numbers.
- Page 8 Keep Giant Up-to-date Upgrade guide...
-
Page 9: Firmware Update
Configuration Mode L Mode H Normal mode DFU Boot mode Firmware Update 01 Before the installation 1. Power off Giant. 2. Remove 5 pin dual row cable connecting two miner boards. - Page 10 3. Set SW3 to H on both boards. 4. plug 4-pin USB cable to USB Con on any of two boards. Make sure Giant is off before connecting 4-pin USB cable. 5. Power the selected board on by plugging in 2 of power cables on the board and check LEDs have lights flow through.
- Page 11 6. It should be followed by pop-up message below. 7. DFU Util would appear as a replacement of STM Device in DFU Mode on Device Manager if installed successfully. 03 Update firmware 1. Run update_firmware_giant.bat and console window would pop up. 2.
- Page 12 04 Finish 1. Power off Giant miner by unplugging power cables. 2. Remove 4-pin USB cable from the miner board and insert it into the other one. 3. Repeat step 01-5 to 03-2 for updating the other one as well.
- Page 13 2. Download Win32diskImager Utility. File : Win32DiskImager-0.9.5-binary.zip Download Link 1 : Google drive 02 Update OrangePl SD Card 1. Turn Giant off. 2. Remove the SD Card from the OrangePI Controller. 3. Read the SD card on your computer and check which drive...
- Page 14 letter it assigned. 4. Run the win32diskImager utility. 5. Select the OrangePI-PC_8G_V2.1_0712.img 6. Select the driver letter of the SD card in the device box. 7. Be careful to select the correct drive; if you get the wrong one you can destroy your data on the computer’s hard disk! 8.
