kiosks
INDEX
By Section
Product
Product Name
Code
KIOSKS
Media Kiosk
HDWT
Media Chat Kiosk
HDWV
May 2022
*Click on the desired Installation Guide to jump to the Guide
page.
Guide
Last
No.
Updated
Product Name
ACCESSORIES
101
May 2022
Framed Fabric Add-On
Framed Whiteboard Add-on
Wire Manager Kit
Product
Guide
Last
Code
No.
Updated
Product Name
NO INSTALLTION GUIDE
201
May 2022
Whiteboard/Taskboard Add-On
HDAF
Storage Kiosk
HDAW
May 2022
202
Gallery Kiosk
HDAZ
Open Felt Kiosk
Servery Kiosk
Open Planter Kiosk
Recycle Kiosk
Mudroom Kiosk
Product
Guide
Last
Code
No.
Updated
HDAB
HDWB
HDWB
HDWF
HDWG
HDWP
HDWR
HDWS
PAGE 1 OF 1
Advertisement
Summary of Contents for Teknion KIOSKS
- Page 1 INDEX *Click on the desired Installation Guide to jump to the Guide By Section page. Product Guide Last Product Guide Last Product Guide Last Product Name Code Updated Product Name Code Updated Product Name Code Updated KIOSKS ACCESSORIES NO INSTALLTION GUIDE...
- Page 2 Guides Section: KIOSK Date: Sept 2022 Page No: 1 of 10 Description: TV MOUNTING TKL_101 Rev. No: 1 Media Kiosk (HDWT), Media Chat Kiosk (HDWV)
- Page 3 Guides Section: KIOSK Date: Sept 2022 Page No: 2 of 10 Description: TV MOUNTING TKL_101 Rev. No: 1 Part and Product Identification TV MTG KIT- COLLABORATION WALL (X01-4350) x1 HDWT B6 - Tech Easel Monitor Bracket D1 - Top Bracket Subassembly -...
- Page 4 Guides Section: KIOSK Date: Sept 2022 Page No: 3 of 10 Description: TV MOUNTING TKL_101 ATTACH TV MOUNT TO TV NOTE: TV is not included with the Kiosk products, it is purchased by the customer. NOTE: Use only what is needed from the mounting screws.
- Page 5 Guides Section: KIOSK Date: Sept 2022 Page No: 4 of 10 Description: TV MOUNTING TKL_101 INSTALL WEBCAM MOUNT (OPTIONAL) ADJUST FOR HEIGHT (OPTIONAL) NOTE: HDWV configurations do not come with a Webcam Mount. B4.1 STEP 2a: Insert the Webcam Mount through the centre gap in the Top Bracket. Position the STEP 2b: Adjust the Webcam Mount to the desired height if necessary.
- Page 6 Guides Section: KIOSK Date: Sept 2022 Page No: 5 of 10 Description: TV MOUNTING TKL_101 INSTALL TECH EASEL MONITOR BRACKET HANG TV ONTO TECH EASEL MONITOR BRACKET NOTE: TV hidden for clarity. STEP 3a: Install Tech Easel Monitor Bracket. Use the pilot holes for placement.
- Page 7 Guides Section: KIOSK Date: Sept 2022 Page No: 6 of 10 Description: TV MOUNTING TKL_101 TURN DISENGAGEMENT LOCK INSTALL DUCT PLATE NOTE: TV hidden for clarity. NOTE: The Duct Plate is for HDWT configurations only. NOTE: TV hidden for clarity.
- Page 8 Guides Section: KIOSK Date: Sept 2022 Page No: 7 of 10 Description: TV MOUNTING TKL_101 INSTALL DUCT COVER REMOVE BOTH P.E.T COVERS NOTE: TV hidden for clarity. STEP 6: Hang the Duct Cover onto the Duct Plate. STEP 7: Remove both PET covers. The bottom one has metal brackets on its top to pull from.
- Page 9 Guides Section: KIOSK Date: Sept 2022 Page No: 8 of 10 Description: TV MOUNTING TKL_101 ROUTE THE TV WIRING ROUTE THE TV WIRING NOTE: For HDWV configurations only. NOTE: Electrics are not supplied with Kiosk. STEP 8a: Slide the wiring through the Duct Plate and Duct Cover and through the gaps that STEP 8b: For the Media Chat Kiosk (HDWV) the wire will be routed through the plastic lead into the bottom.
- Page 10 Guides Section: KIOSK Date: Sept 2022 Page No: 9 of 10 Description: TV MOUNTING TKL_101 PUSH IN THE MOUNTING HANGARS TWIST THE MOUNTING HANGARS PB02-E162 PB02-E162 STEP 9a: Push in the Mounting Hangars into the gaps provided. STEP 9b: Twist the Mounting Hangars clockwise 90 degrees so that they rest on the bracket.
- Page 11 Guides Section: KIOSK Date: Sept 2022 Page No: 10 of 10 Description: TV MOUNTING TKL_101 INSTALL POWER BAR ROUTE THE WIRING FOR THE POWER BAR YEPD400-AC245B-120 STEP 10: Snap the Power Bar onto the the Mounting Hangars. STEP 11: Route the wiring through the bottom grommet or through one of the side cutouts as...
- Page 12 Installation Guides ACCESSORIES Section: Date: May 2022 Page No: 1 of 3 Description: ADD-ON BOARDS TKI_201 Rev. No: 0 Framed Fabric Add-On (HDAF) and Framed White Board Add-On (HDAW) Part and Product Identification A - Framed Fabric Add-on Assembly...
- Page 13 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 2 of 3 Description: ADD-ONs TKI_201 MARK HOLES ATTACH MOUNTING BRACKET STEP 1: Mark the bracket holes after aligning the bracket using tabs as shown. STEP 2: Drill pilot holes and secure the bracket as shown in the figure.
- Page 14 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 3 of 3 Description: ADD-ON TKI_201 BREAK OFF TABS HANG ADD-ON ONTO BRACKETS STEP 3: Break Off tabs from the brackets as shown. ATTACH DUAL LOCK ENGAGED FASTENERS STEP 4: Attach Dual Lock Engaged Fasteners on the bottom of the board as shown.
- Page 15 Installation Guides ACCESSORIES Section: Date: May 2022 Page No: 1 of 6 Description: WIRE MANAGEMENT KIT TKI_202 Rev. No: 0 Wire Manager Kit (HDAZ) Part and Product Identification NOTE: Wire Manager Compatible with HDWG, HDWS and HDWD. A - Cord Loop...
- Page 16 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 2 of 6 Description: WIRE MANAGEMENT KIT TKI_202 INSTALL MOUNTING BRACKET REMOVE WIRE CLIPS NOTE: The Mounting Bracket can also be secured where needed (without lining up with pilot holes) as long as it is screwed in under a shelf and along the Kiosk Wall.
- Page 17 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 3 of 6 Description: WIRE MANAGEMENT KIT TKI_202 SECURE CORD LOOP PEEL ADHESIVE FOR DESK WIRE MANAGER STEP 2b: Screw in the Cord Loop at the desired location. STEP 3: Peel the Adhesive liner off of the Fixed Desk Wire Manager.
- Page 18 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 4 of 6 Description: WIRE MANAGEMENT KIT TKI_202 SECURE DESK WIRE MANAGER SECURE DESK WIRE MANAGER NOTE: Installation on HDWV shown. NOTE: Top Shelf hidden for clarity. NOTE: TV on mount hidden for clarity.
- Page 19 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 5 of 6 Description: WIRE MANAGEMENT KIT TKI_202 SCREW IN WIRE CLIPS STEP 5: Install the 2 Wire Clips where needed. They can be attached to the bottom side of shelves (as shown) or along the Kiosk wall.
- Page 20 Installation Guides Section: ACCESSORIES Date: May 2022 Page No: 6 of 6 Description: WIRE MANAGEMENT KIT TKI_202 ROUTE WIRING NOTE: Power Bar shown is YEPD-7. It is not included with the Wire Management kit. STEP 6: Route the wires through the different section of the Wire Management Kit. This is an example of how the Wire Management Kit can be used to manage cables and wires.
