Page 1 User Manual Dryer WDR80S...
Page 2: Please Read This User Manual First
Please read this user manual first! Dear Customer, Thank you for prefering a Voltas.Beko product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference.
Page 3: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • The dryer can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are...
Page 4 Important instructions for safety and environment 1.1.1 Electrical safety Electrical safety instructions should be followed while electrical connection is made during the installation. The appliance must not be supplied through an external switching device, such as a timer,or connected to a circuit that is regularly switched on and off by utility.
Page 5 Important instructions for safety and environment If the dryer is faulty, it must not be operated unless it is repaired by an authorized service agent! There is the risk of electric shock! 1.1.2 Product safety Superheating of the clothes inside of the dryer can occur if you cancel the programme or in the event of a power failure whilst the dryer is running, this concentration of heat can cause self-combustion and...
Page 6 Important instructions for safety and environment Below specified laundry or items must not be dried in the dryer due to the fire hazard: • Garments or pillows bolstered with rubber foam (latex foam), shower bonnets, water resistant textiles, materials with rubber reinforcement and rubber foam pads.
Page 7 Important instructions for safety and environment the required procedure unless it is clearly suggested in the operating instructions or the published service manual. Otherwise, you will be putting your life and others’ lives in danger. • There must not be a lockable, sliding or hinged door that may block the opening of the loading door in the place where your dryer is to be installed.
Page 8: Intended Use
Important instructions for safety and environment Washing machine cannot be placed on the dryer. Pay attention to the above warnings during the installation on your washing machine. Installation Table for Washing Machine and Dryer Washing Machine Depth Dryer Depth 62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm Can be...
Page 9 Important instructions for safety and environment 1.5 Compliance with the WEEE regulation and disposing of the waste product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling.
Page 10 Important instructions for safety and environment 1.8 Technical Specifications Height (Min. / Max.) 84,6 cm / 86,6 cm* Width 59,7 cm Depth 58,9 cm Capacity (max.) 8 kg** Net weight (± 4 kg) 46 kg Width Voltage See type label*** Rated power input * Min.
Page 11: Your Dryer
Your Dryer 2.1 Package Contents 1. Water drain hose * 2. Filter drawer spare sponge* 3. User Manual 4. Drying basket* 5. Drying basket user manual* *It can be supplied with your machine depending on its model. Dryer / User Manual 11 / EN...
Page 12: Appropriate Installation Location
Installation Before the calling the nearest Authorized Do not place the dryer on the Service for the installation of the dryer, power cable. ensure that electrical installation and water drain is appropriate referring to the user’s 3.2 Removing the manual. If they are not suitable, contact a transportation safety qualified electrician and technician to make assembly...
Page 13: Adjusting The Feet
Installation Connecting the water drain 3.4 Adjusting the feet • In order to ensure that the dryer hose operates more silently and vibration- Pull hose at the behind of the dryer free, it must stand level and balanced by hand in order to disconnect it from on its feet.
Page 14: Changing The Illumination Lamp
Installation 3.7 Warnings about sounds It is normal to hear a metallic noise from the compressor sometimes during operation. Water collected during operation is pumped to water tank. It is normal to hear pumping noise during this process. 3.8 Changing the illumination lamp In case an illumination lamp is used in your laundry dryer.To change the Bulb/LED used...
Page 15: Laundry Not Suitable For Drying In The Dryer
Preparation 4.1 Laundry suitable for drying in the dryer Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are suitable for drying in a dryer and make sure that you select the appropriate programme.
Page 16: Correct Load Capacity
Preparation • Do not add wet laundry while the dryer is Following weights are given as examples. in operation Approximate Laundry • Clean the lint filter before or after each weights (g)* drying cycle. Cotton quilt covers • Clean the filter drawer periodically when 1500 (double) there is visible air collection on it or...
Page 17: Operating The Product
Operating the product 5.1 Control panel Program selection knob Remaining duration indicator On/Off button 4. Start/pause button End duration button Sound warning button 5.2 Screen symbols Child-proof Filter Tank Volume up Mute Anti full lock cleaning Creasing Dryer / User Manual 17 / EN...
Page 18: Program Selection
Operating the product 5.3 Preparing the machine 5.5 Main programs Plug in the machine The main programs are given below based on Place laundry inside the machine. fabric type. Press the On/Off button. • Cotton 4. When your machine turns on for the first Dry durable laundry with this program.
Page 19 Operating the product Very little dampness might remain on the shirts after the program. It is recommended that you do not leave the shirts in the drying machine. • Delicates You can dry your delicates suitable for drying or laundry that is recommended to hand wash (silk blouses, thin underwear etc.) in low temperature.
Page 20 Operating the product 5.7 Program selection and consumption table Spin speed in washing Approximate amount Programs Capacity (kg) of remaining humidity Drying time (minutes) machine (rpm) Cottons / Coloreds Extra dry 1000 % 60 Cupboard dry 8 / 4 1000 % 60 197 / 115 Iron dry...
Page 21: Warning Symbols
Operating the product 5.8 Auxiliary functions Sound warning cancel Drying machine makes sound warnings when the program is completed. If you don’t want sound notifications, press the “Sound Notification” button. Loading door open When you press the sound notification Start/Pause led blinks when the loading door button it lights up, and program does not of the drying machine is open.
Page 22: Starting The Program
Operating the product Repeat the end duration operation for The lock led on the screen the duration you want. lights up when the Child Lock is 4. Start the program by pressing the Start / activated. Pause button. Canceling the end duration function Child Lock deactivates when the If you want to cancel the end duration machine is turned off and on...
Page 23: Program End
Operating the product 5.15 Program end The laundry adding made after When the program ends, the Final/Wrinkle the drying operation started may Prevention, Fiber Filter Cleaning and Water cause the dried laundry inside Tank Warning leds on the program follow the machine to mix with the up indicator light up.
Page 24: Maintenance And Cleaning
Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 6.1 Cleaning Lint Filter / Loading Door Inner Surface Lint and fiber released from the laundry to the air during the drying cycle are collected in the Lint Filter.
Page 25: Draining The Water Tank
Maintenance and cleaning Pull the drawer and remove the water tank Clean metal surfaces of the carefully. sensors 4 times a year. Do not use metal tools when cleaning metal surfaces of the sensors. Never use solvents, cleaning agents or similar substances for cleaning due to the risk of fire and explosion! •...
Page 26 Maintenance and cleaning 6.4 Cleaning the filter drawer • Open the filter drawer by pressing the red button. Lint and fiber that could not be captured by the lint filter are blocked in the filter drawer behind the kick plate. Clean the filter periodically when there is visible air collection on it or when the symbol lights up,...
Page 27: Cleaning The Evaporator
Maintenance and cleaning A dirty lint filter and filter drawer will cause longer drying periods and higher energy consumption. 6.5 Cleaning the evaporator Clean the lint accumulated on the fins of the evaporator located behind the filter drawer with a vacuum cleaner. •...
Page 28: Troubleshooting
Troubleshooting Drying process takes too much time. • Pores of the lint filter are clogged. >>> Wash the lint filter with warm water. • Filter drawer may be blocked>>>clean the foam inside the filter drawer. • Ventilation grids on the front side of the machine are blocked. >>> Remove the objects (if any) that block ventilation in front of the ventilation grids.
Page 29 Troubleshooting Drum lighting does not turn on. (On models with lamp) • Dryer is not switched on with the On / Off button. >>> Make sure that the dryer is switched on. • Lamp is defective. >>> Call Authorized Service Agent to have the lamp replaced. End/Anti-creasing symbol is on.
Page 30 PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 392/2012 Voltas.Beko Supplier name or trademark WDR80S Model name Rated capacity (kg) Air Vented Type of Tumble Dryer Condenser Energy efficiency class Annual Energy Consumption (kWh) Automatic Type of Control Non-automatic Energy consumption of the standard cotton programme at full load (kWh) 1,95 Energy consumption of the standard cotton programme at partial load (kWh) 1,06...
Page 32 all center number : (1860 599 4444) service e mail : wecare@voltasbeko.com 2960311740/030418.1713...
