Making British gardens great
LEAN-TO LOG STORE
INSTRUCTIONS
We recommend using the following
tools (not supplied):
Tape Measure
Pozidrive
Screwdriver
Hand Saw
Fit For Purpose
Ladder
1
Whilst attaching the roof, the lean-to log store can now
be assembled. Detach the middle Cover Strip(s) from
the side you are attaching your log store.
IMPORTANT
Assembly requires 2+
adults.
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland
Drill & 2-3mm
Drill Bits
Hammer
FIXING PACK CONTAINS:
FIXING PACK CODE: LTLSMFP
CHECK AND TIGHTEN ALL THE FIXINGS APPLIED TO THIS PRODUCT ON A REGULAR BASIS.
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
Using the hand saw, cut the middle Cover Strip(s)
down by 20mm. Re-attach the middle Cover Strips(s)
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
back to their original place.
REMINDER
Always pre-drill before
screwing.
ISSUE: 0123
Mending Plate
QTY: 2
Advertisement
Summary of Contents for Forest LEAN-TO LOG STORE
- Page 1 Fit For Purpose Hammer Ladder Whilst attaching the roof, the lean-to log store can now Using the hand saw, cut the middle Cover Strip(s) be assembled. Detach the middle Cover Strip(s) from down by 20mm. Re-attach the middle Cover Strips(s) the side you are attaching your log store.
- Page 2 6x4 ONLY 7x5 & 8x6 ONLY SCREWS FLOOR FLOOR Position the Floor next to the shed. This will now be Turn the Floors upside down and connect them together able to fit underneath the cut Cover Strip(s) as shown using the mending plates. Position the Floor next to above.
- Page 3 7x5 & 8x6 ONLY ROOF ROOF Position the Roof. Ensure the Roof is butt up to the If you have 3 x Posts, ensure the central Post is up shed’s roof and the Posts sit inside the framework. against the middle batten attached to the Roof. SCREWS SCREWS SCREWS...
-
Page 4: Health And Safety
7x5 & 8x6 ONLY SCREWS SCREWS Fix the Roof to the side Posts as shown above. Fix the Roof to the central Post as shown above. FASCIA Follow the main assembly instructions to begin felting Position and secure the Fascia’s to the log store once your shed, and then continue down to felt your log the sheds Fascia’s have been attached. - Page 5 Contact our aftersales team with your product code if you are missing your felt. 7x5 Lean-To Log Store (OPA57LTKM) CHECK YOU HAVE ALL YOUR PARTS PRIOR TO ASSEMBLY. 6x4 Lean-To Log Store (OPA46LTKM) Label Part Code Description Label Description Part Code...
