- Page 1 Agrumino Lemon Dev Guide - rev 1.2_ENG Agrumino Lemon Dev Guide rev 1.2 _ENG Autore: LifelyTeam Versione: March 2021 ┤1├...
-
Page 2: Installation
Agrumino Lemon Dev Guide - rev 1.2_ENG 1 INTRODUCTION This document provides a guide to install Agumino Board and its libraries. Moreover it describes some example sketches, part of the Agrumino libraries. 2 INSTALLATION 2.1 INSTALL THE USB DRIVER Modern Windows installations seem to automatically install the USB driver. If you’re on another platform, like Mac OS/Linux/Android or Windows, which doesn’t recognize the Serial... - Page 3 4. Now you must select Agrumino via the menu Tools→ Board→ ESP8266 Boards and select Lifely Agrumino Lemon v4. If everything has been done correctly, you should see Lifely Agrumino Lemon at the bottom of the Arduino IDE as in the spot highlighted in the image below.
- Page 4 2.2.1 IF YOU HAVE PROBLEM WITH SETUP IN STEP 2.2 In order to use Agrumino Lemon, it is very simple to install the Official Lifely Agrumino Lemon library. This can be done directly from the library manager in the Arduino IDE.
-
Page 5: Programming The Board
1. Using any available device with WiFI, log in via a browser to connect to the newly created access point (look for SSIDs such as Agrumino-XXXX, where XXXXX is the unique Id of the Lifely Agrumino Lemon card) 2. Enter the DNS server IP in your browser (192.168.4.1) and click on 'Configure Wifi'. - Page 6 Agrumino Lemon Dev Guide - rev 1.2_ENG 3. If step 1 is unsuccessful (or if there is no previous configuration), the card is moved to "Access Point" mode and reactivates the Web Server (default ip 192.168.4.1) and the WiFi network configuration procedure must be repeated.
-
Page 7: Hardware Components
Agrumino Lemon Dev Guide - rev 1.2_ENG Example sketch with Citrus Lemon, using other sensors, actuators, third-party cards such as OLED display, water pump etc. For the time being there is only one sketch for using and displaying data via an I2C oled display ●... - Page 8 Agrumino Lemon Dev Guide - rev 1.2_ENG Light SW1-1 (Left) Temperatur Battery recharge ON- User Reset WiFi Micro USB connector for Battery Internal Soil 6.2 Agrumino board back Water sensor Wifi GPIO Antenna Connector External Pump LiPo connecto connector Soil...
-
Page 9: Visual Guide
Agrumino Lemon Dev Guide - rev 1.2_ENG 7 FAQ & Common Errors error: cannot access ... EB#*F!G&(.!'B#!46(()$!C!H(&'?!.#0%!'BA'!'B#!$#)#*'#>!I(A&>!/$!'B#!*(&&#*'!(0#!A0>! 'BA'!/'J$!*(00#*'#>D!KG!('B#&!L;"!>#2/*#$!A&#!*(00#*'#>M!*B#*F!'B#!(0#!*(&&#$N(0>/0-! '(!,-&%./0(!1#.(0D espncom sync error Press the reset button on the Agrumino (S2 on the Top-Left) and try again. If the error happens again disconnect the Agrumino from the USB, remove and reconnect the jumper P1 and try again. - Page 10 Agrumino Lemon Dev Guide - rev 1.2_ENG and click Now go to: Tools Board Boards Manager and click In the text box, type ESP8266 and click on Install. Important, only install version 3.0.0 or later. ┤10├...
- Page 11 Agrumino Lemon Dev Guide - rev 1.2_ENG After completing the installation click on Close. Agrumino Lemon v4 Go to Tools Board Esp8266 Boards (3.0.0) click If the choice was successful, you should see “Lifely Agrumino Lemon v4” at the bottom right on Arduino IDE ┤11├...
- Page 12 Agrumino Lemon Dev Guide - rev 1.2_ENG Now you have to install the official library, so go to: Tools Library Manager and type “Agrumino Lemon” or simply “Lifely” (see image below). Having done this, you must now click on Install (always install the latest release).
- Page 13 (see arrow no. 1) next, change the "baud rate" to 115200 (see arrow no. 2) and now you can finally view the data acquired by your Agrumino Lemon (see arrow no. 3) ┤13├...
- Page 14 Agrumino Lemon Dev Guide - rev 1.2_ENG From now on, you can manage your device. Also try the other sketches in the examples folder of Lifely Agrumino Lemon. For support visit www.lifely.cc ┤14├...
