Summary of Contents for EDEN INNOVATIONS OPTIMA BOX+
-
Page 2: Table Of Contents
No part of this publication may be reproduced, transmitted, transcribed or translated in any form or by any means without the consent of the copyright holder. Unauthorized copying can not only break the laws of copyright but also reduce the ability of Eden Innovations to provide accurate information. -
Page 3: Package Contents
Cables to connect the backup battery Warranty Eden innovations guarantees that its products will be free from defects in material and workmanship, under normal use, for a minimum period of 5 years from the date of manufacture indicated on the model label or from the date of invoice. -
Page 4: Information And Recommendations
Make sure you obtain all the necessary written authorization. Do not accept any oral authorization, as this is not valid. EDEN INNOVATIONS Company recommends never using its equipment as a primary warning system or surveillance system. These must always conform to the regulations in place relating to fire risk and safety. -
Page 5: Technical Characteristics
OPTIMA Box+®–Technical Instructions–v.1.1 5/12 Technical characteristics Case: Weight............3,38 kg Dimensions..........370 x 230 x 85 mm Built-in 230V power supply: Voltage............100V - 240V Frequency............ 50Hz - 60Hz Output voltage..........13.8V Maximum output current......A Temperature ..........0°C +40°C Connection for the battery...... -
Page 6: Installing The Case
OPTIMA Box+®–Technical Instructions–v.1.1 6/12 Installing the case 1) General The use of boxes indoors is recommended. Outdoor use must be done in a minimum IP54 enclosure. In the case of a completely waterproof case, lead-acid batteries should not be used. The product should not be installed at an altitude of more than 2000m. - Page 7 OPTIMA Box+®–Technical Instructions–v.1.1 7/12 Connect the cable area to the terminal area as follows: • The blue wire on the terminal marked N (Neutral) • The green/yellow wire on the terminal marked with the label “Earth” • The brown wire on the terminal marked with an L (phase) Make sure that in the event of poor fixing, the power supply terminal must not be able to touch the metal casing.
-
Page 8: Battery
OPTIMA Box+®–Technical Instructions–v.1.1 8/12 5) Commissioning (power supply) Open the circuit breaker before connecting anything. After having made the electrical connections (uses then mains). 1. Close the circuit breaker first. 2. Check the output voltage. The AC & DC LEDs turn green. 3. -
Page 9: System Shutdown
OPTIMA Box+®–Technical Instructions–v.1.1 9/12 Connecting the OPTIMA Box to the Ethernet network SWITCH OR ROUTEUR Please use a RJ45 Cat5e FTP shielded wire (or shielded F/UTP). The use of the PoE (Power over Ethernet) function on the Ethernet bus is not permitted. The maximum wire length between the device and the switch must not exceed 100m. -
Page 10: Maintenance
OPTIMA Box+®–Technical Instructions–v.1.1 10/12 Maintenance This section gives you the important elements to take into account when maintaining the OPTIMA Box®. Warning : There is a risk of explosion if the battery or battery is replaced by an incorrect type or battery. -
Page 11: Led Signage
OPTIMA Box+®–Technical Instructions–v.1.1 11/12 LED signage 1) Power supply State Meaning Solution Main supply present Check that the power supply is connected to the Main supply absent mains Active DC outputs Check the mains supply DC outputs inactive Use a battery Battery present BATT Battery empty or... - Page 12 OPTIMA Box+®–Technical Instructions–v.1.1 12/12...
