TECHNICAL INSTRUCTIONS
ATTENTION! It is very important for the safety of people to follow all instruc-
1
tions strictly. A wrong installation or use of the product could cause serious
damage to people.
Read carefully this manual before starting installation and save it for future
2
reference.
Packaging materials (i.e. plastic, polystyrene, etc.) must be out of children's
3
reach, because potentially dangerous.
This product has been designed and manufactured exclusively on the purpose
4
indicated in this manual. Any different use not here indicated could damage the
integrity of the product and/or be potentially dangerous.
AccessPRO INDUSTRIAL is not responsible for any damage caused by impro-
5
per or different use from the indicated one.
6
be not safe.
7
Installation must be according to the local Laws.
In order to have an adequate safety level in the extra-CEE
8
countries, in addiction to the national laws, the above mentioned laws must be
followed.
AccessPRO INDUSTRIAL is not responsible if someone does not observes the
9
correct method of installation of the AccessPRO INDUSTRIAL products and
related devices, included deformations coming during the use.
10
Before any actions on the automatic installations take power off.
An Omni polar switch should be foreseen on the alimentation' s net of automatic
11
installations. Its connections should have an opening range of 3 mm. A magne-
totermical differential with 6A Omni polar switch is adviceable
Assure that a differential switch with 0,03° is present at the
12
beginning of the automatic installation.
The main electrical alimentation of the control unit of automatic installations
must be connected directly to at the beginning of the apposite principal switch
13
minimum 3x2,5mm,but evaluated by the installer according to the number of
AccessPRO INDUSTRIAL bollards (400W each AccessPRO INDUSTRIAL
bollard) and the distance from the output point in order to guarantee a correct
alimentation (230V +/- 10% for moving AccessPRO INDUSTRIAL bollard).
14
Test that the earthing is workmanlike and connect the metallic parts.
The automatic installations include a standard safety device: an inversion
15
pressure switch in case of at least 40 kg of load. It is anyway necessary to test
the activation level every six months, according to what laws establish.
Safety devices (Law EN 12978) allow protection of potentially dangerous areas
16
where activities such as squashing, conveyance, shearing are possible to
occur.
WARNINGS FOR THE INSTALLER – GENERAL SAFETY OBLIGATIONS
integrated in the crosshead of the bollard) and a signal placard, along with the device
17
quoted at point "16" 2 Read carefully this manual before starting installation and save it
for future reference. 18 In each automatic installation the installer must consider.
In each automatic installation the installer must consider and install appropriate safety
18
devices.
19
For maintenance works use only original parts supplied by AccessPRO INDUSTRIAL.
AccessPRO INDUSTRIAL is not responsible for safety and good functioning of the
20
product , in case of use of components not manufactured or distributed by AccessPRO
INDUSTRIAL.
21
PRO INDUSTRIAL.
The installer must provide the Customer with all information related to the manual relea-
22
se of the automatic bollard in case of emergency and give the User a warning manual
attached to the product.
23
Do not allow children or others to stop close to the bollard during operation.
Keep remote controls or other impulse-giving devices out of children's reach, in order to
24
avoid involuntary activation.
Thoroughfare over the AccessPRO INDUSTRIAL bollard allowed only at complete
25
lowering of the bollard.
Semiautomatic bollards are not adviceable for multiple installation (two or more) on
26
main streets where the frequent passage of vehicles over the lowered bollards can
break the lock block and make the bollard lifting without control.
The User must avoid any repairing actions or direct operations on the bollard, and must
27
Do not waste exhausted batteries in the garbage, but dispose them in the apposite con-
28
tainers to allow recycling. Disposal costs have already been paid by the manufacturer.
The product is packaged on Euro pallet; use pallets' movers or shunters for movement;
29
handle
with care.
The product has been manufactured with IP 56 protection's level, and could therefore
30
be stored everywhere; storage in internal or covered places is anyway preferable.
The product does not require availability of spare parts; AccessPRO INDUSTRIAL's
31
warehouse can send by express any needed spare parts.
In case of maintenance and/or reparation, Pay attention not to give improper raising
32
signals; to avoid any problems, disconnect the bollard's moving by the switch set inside
the control management station.
33
Everything not mentioned in this manual is not allowed.
XB220H06K
-
