Original
operating manual
Operating manual
Fork-mounted crane jib
GAB1-series
Flexibility & experience
06/2021 – V01
from serial n° 500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAB1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for cam GAB1 Series

  • Page 1 Original operating manual Operating manual Fork-mounted crane jib GAB1-series Flexibility & experience 06/2021 – V01 from serial n° 500...
  • Page 2 © 06-2021. CAM attachments is a trademark of TVH Parts Holding NV, Brabantstraat 15, B-8790 Waregem. All rights reserved. No part of this publication may be reproduced or communicated in any form or by any means, electronic or mechanical, including copying, recording or use in an information storage or retrieval system, without prior and explicit permission of TVH Parts Holding NV.
  • Page 3 Bulgarian Можете да намерите това ръководство на Вашия език чрез линка, посочен по – долу. Czech Tento návod najdete ve svém jazyce prostřednictvím odkazu níže. Danish Du kan finde denne vejledning på dit sprog via nedenstående link. German Sie finden diese Bedienungsanleitung in Ihrer Sprache unter folgendem Link. Greek Μπορείτε...
  • Page 4 Thank you for using our product. For your safety and to ensure a correct operation, we would like to bring to your attention some aspects of this manual: • This booklet supplies useful instructions for the correct operation and maintenance of the product. It is therefore necessary to pay the utmost attention to all of the paragraphs that illustrate the most simple and secure way to operate and use this product.
  • Page 5: Table Of Contents

    CONTENTS INTRODUCTION ..................... DESCRIPTION .
  • Page 6: Introduction

    INTRODUCTION This manual contains all the necessary information on the installation and operation of the fork- mounted crane jib. Some of the maintenance operations should only be carried out by professional technicians. If you require this information and the maintenance steps, please contact your dealer. Also included in this manual are a number of safety instructions to create a safe working environment.
  • Page 7: Description

    DESCRIPTION 2.1. Technical data Always check the type plate for the correct information. The load diagram is mentioned under chapter 3. Safety instructions – 3.2. Load diagram. Model BA52814 Load capacity (kg) 2000 Load centre (mm) Maximum arm length (L2) (mm) 1750 Maximum fork spread measured over the forks (W11) (mm) Fits maximum fork section (mm)
  • Page 8: Main Components Of The Product

    2.2. Main components of the product N° Component Safety locking pin Fork sleeves Mounting plate for load hook with shackle Mounting hole for load hook Swivel hook Bow shackle Cotter pin 8/28...
  • Page 9: Placement Of The Decals

    Observaciones: hay que comprobar regularmente si el tornillo de los enganches está completamente atornillado CAM ATTACHMENTS® Brabantstraat 15 • 8790 Waregem • Belgium T +32 56 43 42 11 • F +32 56 43 44 88 www.camattachments.com •...
  • Page 10: Type Plate

    2.4. Type plate N° Explanation Manufactured outside the EU for: TVH PARTS HOLDING NV Address Brabantstraat 15 • 8790 Waregem • Belgium CE logo CAM attachments logo TYPE Type MODEL Model MODÈLE MODEL MODELL SERIENR. Serial number ° SÉRIE SERIAL NBR...
  • Page 11: Safety Instructions

    SAFETY INSTRUCTIONS 3.1. Explanation of the safety decals Make sure that all the safety messages are legible. Replace damaged stickers asking the manufacturer for new ones. If the part to be replaced bears a sticker, ensure that a new sticker is applied to the new part. Take care to avoid being struck by or walking into an overhead load (REF 123TA5325).
  • Page 12: General Safety Instructions

    In the event that equipment, procedures, work methods or working techniques are used that are not specifically advised by the CAM attachments company, it is necessary to make sure that there is no danger to the operator or other people.
  • Page 13: Transport And Storage

    TRANSPORT AND STORAGE 1. Storage The fork-mounted crane jib must always be stored in a dry, frost-free and temperature-controlled environment. Avoid direct sunlight. Do not store this product outside in a wet environment. Store the fork-mounted crane jib in a safe place and make sure it can’t fall over. Lubricate metal parts with an anti-corrosive agent (REF 166TA1570 or REF 143TA6901).
  • Page 14: Assembly And Installation

    • The assembly and installation must be carried out by an expert. • Make sure that the goods and packaging are in good condition. • Before commissioning, carry out a risk analysis on the assembly of the CAM attachment with the forklift.
  • Page 15: Commissioning

    COMMISSIONING • The lifting device with attachment installed needs to be approved for use prior to commissioning. • Be sure to obtain the manufacturer’s certification concerning the residual capacity of the lifting device, after installing the attachment. • Provide a capacity table within sight of the driver from the lifting device. 6.1.
  • Page 16: Operation

    • For safety reasons, arbitrary adaptations or modifications to the equipment are prohibited. • In the event of non-envisaged workmanship or intervention or following a procedure different to that indicated in the manual, consult CAM attachments before proceeding in order to ascertain its feasibility.
  • Page 17: Operating Instructions

    • Do not lift loads on inclines or gradients. • Make sure that the load cannot move or fall. • Before using the crane jib, carefully read the instructions in the manual of your lifting device. 7.2. Operating instructions Please see chapter 8 for the daily maintenance schedule. Perform the daily maintenance check before each use as described in chapter ‘8.3.
  • Page 18: Maintenance

    MAINTENANCE A fork-mounted crane jib is a lifting device. Comply with the obligation to perform periodic inspections if required according to national legislation. 8.1. Safety instructions for the maintenance of the product • For maintenance, place the fork-mounted crane jib in its lowest position to the ground. Switch off the vehicle’s engine and remove the key.
  • Page 19 3. Cleaning Only clean the equipment with a cloth dampened in a soap solution (REF 131TA5500)* or TotalSource wipes (REF 147TA3378). Do not use solvents, petrol, strong detergents etc. If the equipment is heavily soiled, the use of a pressure cleaner is only permitted providing that it is set to a maximum of 200 bar.
  • Page 20: Troubleshooting

    TROUBLESHOOTING N° Problem Cause Action Damaged swivel Frequent or improper use. Replace the swivel hook or bow shackle hook/bow shackle. with a new one. See chapter 5. ‘Assembly and installation’ for assembling the bow shackle and swivel hook. See spare parts list for the correct reference.
  • Page 21: Final Decommissioning And Disposal

    FINAL DECOMMISSIONING AND DISPOSAL Final, proper decommissioning or disposal of the product must be performed in accordance with the regulations of the country in which the product is used. In particular, regulations governing the disposal of batteries, fuels and electronic and electrical systems must be observed. Waste packaging should be sorted and put into solid dustbins according to the materials and be collected by the local special environmental protection bureau.
  • Page 22: Annexes

    ANNEXES 11.1. CE-certificate 22/28...
  • Page 23 23/28...
  • Page 24: 11.2. Spare Parts List

    11.2. Spare parts list 1. BA52814 Photo Description Reference 2T jib 166TA8145 Locking pin 166TA3452 Linch pin 106TA6976 Cotter pin 106TA6982 Bow shackle with safety pin 134TA8279 Swivel hook with safety latch 143TA6394 24/28...
  • Page 25 2. BA52818 Photo Description Reference 4T crane jib 166TA8146 Locking pin 166TA3452 Linch pin 106TA6975 Cotter pin 106TA6982 Bow shackle with safety pin 134TA8281 Swivel hook with safety latch 143TA6396 25/28...
  • Page 26 NOTES ................................
  • Page 27 NOTES ................................
  • Page 28 Your distributor: Manufactured outside the EU for TVH PARTS HOLDING NV. www.camattachments.com Agri info@camattachments.com Construction Industry Brabantstraat 15 Food & 8790 Waregem beverage Belgium Paper T +32 56 43 42 11 handling F +32 56 43 44 88...

This manual is also suitable for:

Ba52814Ba52818
