SPECIFICATIONS / SPECIFICATIES
Input transmitter:
Output Transmitter:
Transmitter power supply:
Receiver Input:
Receiver output:
Receiver power supply:
Resolution:
User Manual:
PACKAGE CONTENT / IN DE VERPAKKING
1x HDMI Receiver & Transmitter
1x IR TX cable
1x IR RX cable
1x Power Supply DC 5V
2x Mounting Bracket
1x Manual
Cavus International, Inc.
P.O. Box 4007
New York, NY 10163-4007 (USA)
Phone: (+1) 347-577-9022
Mail: info@cavusmounts.com
HDMI in, Infrared in
RJ45 / CAT6
5V DC
RJ45 / CAT6
HDMI out, Infrared out
Poc (Power over cable)
480i / 480p / 576i / 576p / 720p / 1080i / 1080p
English / Nederlands
Cavus International
P.O. Box 81
2150 AB, Nieuw-Vennep
The Netherlands
info@cavus.eu
INSTRUCTIONS
HANDLEIDING
HDMI EXTENDER
Install this extender according to this guide and prevent damage
Installeer deze extender volgens deze handleiding en voorkom schade.
CAV-BXHD01
Advertisement
Related Manuals for Cavus CAV-BXHD01
Summary of Contents for Cavus CAV-BXHD01
- Page 1 1x HDMI Receiver & Transmitter 1x IR TX cable 1x IR RX cable 1x Power Supply DC 5V 2x Mounting Bracket 1x Manual Cavus International, Inc. Cavus International P.O. Box 4007 P.O. Box 81 New York, NY 10163-4007 (USA) 2150 AB, Nieuw-Vennep...
- Page 2 CAV-BXHD01 Cavus recommends that the installation should be carried out by a skilled installer. If the use and/or installation is not carried out correctly, this may cause personal injury and damage to your equipment and other objects. Cavus cannot be held liable for IR/RX IN personal injury and any damage done to objects caused by incorrect use and / or installation.
