Technical Specification Sheet - EBOX 1.6 Owner's Manual

The motor controller is located within
the frame of the bike between the
battery and rear shock.
Response
This controls the throttle response of
the bike. Turn the adjustment knob
clockwise to increase and
anti-clockwise to decrease.
Attention, we recommend tuning
the response to its lowest setting
when children and new users are
riding the bike.
Speed
Turning the dial clockwise will
increase the top speed of the bike,
anti-clockwise will lower it.
ATTENTION
We recommend re-checking all parts after the first ride to ensure they are
still correctly tightened and have not come loose. We
recommend special attention be paid to the following parts:
- Foot pegs
- Motor sprockets
- Shock absorber
- Motor bolts and nuts
- Rear sprocket
- Wheels
- Chain Tension
- Brakes and Callipers

TECHNICAL SPECIFICATION SHEET

MODEL
Motor
MOTOR
controller
location
MAX SPEED
FINAL DRIVE
CONTROLLER
OUTPUT
BATTERY
CHARGER
CHARGE TIME
RANGE PER CHARGE
FRAME
SUBFRAME
HANDLEBAR
FRONT SUSPENSION
REAR SUSPENSION
BRAKE SYSTEM
DISC BRAKE
FRONT/REAR RIM
FRONT/REAR TYRE
WHEELBASE
GROUND
CLEARANCE
SEAT HEIGHT
MAX LOAD
N.W/ G.W
BIKE DIMENSIONS
PACKING SIZE
EBOX 1.6
48V 1600W - BLDC motor 60V 2000W - BLDC Motor
30mph
10t/ 70t, chain 219H
42A
48V/ 15.6Ah lithium
110-240v/ 54.6V 2A
7-8hrs
17-19miles
High tensile steel double cradle tube frame, powder coated
Removable
Aluminium Ø 22mm
Upside-down forks, Φ39x Φ41, 550mm
Mono shock 270mm
Hydraulic brake
F/R Ø 180mm
1.4 x 12", 1.6 x 10"
2.75 x 12", 3.0 x 10" 60/100 x 14", 80/100 x 12"
940mm
235mm
630mm
85kg
40.5kg/ 50kg
1330 x 645 x 850mm 1400 x 645 x 890mm
1220 x 380 x 640mm 1250 x 380 x 640mm
EBOX 2.0
33mph
45A
60V 18.2Ah lithium
110-240V, 67.2V 2A
20-23miles
1.4 x 14", 1.85 x 12"
955mm
255mm
660mm
42.5kg/ 52kg
