- Page 1 Teddy Pardo DBX Venue 360 Conversion Kit Quick Startup Guide Teddypardo.com/dbx360 info@teddypardo.com...
- Page 2 Remove top screws using Allen key (or Torx #20) • Step 1: Remove the power cord. Remove the top cover, using a Philips screwdriver for the side and back screws, and an allen key (Torx #20 also works) for the front panel screws.
- Page 3 • Step 2: remove the 3 screws holding the power supply in place. Remove the ground wire and the main power plugs.
- Page 4 • Step 3: using a flat screwdriver, push the power socket clips and push out the power entry socket.
- Page 5 • Step 4: Repeat step 3 at the bottom side, remove the power entry socket.
- Page 6 • Step 5: Cut the power supply wires, cut the fan wires.
- Page 7 • Step 6: use a sharp knife and tweezers to remove the heat shrink from the power connector. Use a soldering iron to remove the remaining wires from the connector.
- Page 8 • Step 7: place the panel adapter, place the 3mm screws.
- Page 9 • Step 8: place the panel adapter fasteners, place the 3mm bolts. Note: do not over-tighten the screws!
- Page 10 • Step 9: Place the power connector, secure the cable with a cable tie.
- Page 11 • Product assembly is completed, replace the top cover.
- Page 12 • Attach the power supply cable and power on to verify operation. Replace the top cover, installation is now completed.
