Keep the address of the company.
SOL-EXPERT
SOL-EXPERT
group
group
Not suitable for children under 3 years!
group
group
Contains small parts!
Item no.: 40306
10+
10+
How you can help the
environment: Please
return the parts to a
certified provider at the
end of their useful life!
Solar Racing Car
Wooden building kit with
gearbox, runs on "solar fuel"
SOLAR
Advertisement
Summary of Contents for Sol-Expert Solar Racing Car
- Page 1 Solar Racing Car How you can help the environment: Please Wooden building kit with return the parts to a Keep the address of the company. certified provider at the SOL-EXPERT SOL-EXPERT group group Not suitable for children under 3 years! gearbox, runs on "solar fuel"...
- Page 2 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS, parts: Carefully remove this 60 mm part (2) from the wooden board. (You only need 2 gears, one is a spare) Find the following parts and lay them out: Place the small gear on the table and carefully slide the motor shaft into the small gear from above.
- Page 3 Now slide the motor into the gearbox casing. Turn the motor so the cable comes out at the bottom. Find the following parts and lay them out: The cable must be here! Find the following parts and lay them out: 60 mm Take the 60 mm shaft (use the ruler at the right to measure if the length is correct) and carefully tap it into the double gear (the...
- Page 4 Now slide the second double gear, with the large gear in front, onto the bolt in the gearbox casing. Then assemble the gear/shaft assembly (B). Also slide this with the large gear in front into the hole for the shaft guide. If you now slightly turn the shaft, all gears must turn.
-
Page 5: Assembly Order
ASSEMBLING THE RACING CAR Carefully read the information below before starting assembly: Part You will need to apply glue in the red areas just before assembly. Use glue sparingly. You can clean excess glue with Glue notice: a cloth. Close the glue after assembly. Perhaps you can use it for another project. - Page 6 PARTS: Carefully remove the individual wooden parts from the wooden board: 50 mm M3 x 20 mm...
- Page 7 Find the following parts and lay them out: (4.) (3.) (1.) (2.) TIP: Apply glue thinly here!
- Page 8 Find the following parts and lay them out: TIP: Apply glue sparingly Note...
- Page 9 Note Important note: You need to glue the correct side of part 1 onto the body: i.e. there are two notches at the back which must be in the correct location. (3.) (4.) (1.) (3.) Allow glue to dry for 10 min. (4.)
- Page 10 Find the following parts and lay them out: Important note: Part 15: The notch in the spoiler faces the back of the racing car (2.) (3.) (3.) (4.) (1.) (4.)
- Page 11 Find the following parts and lay them out: (2.) M3 x 20 mm (2.) (1.) (1.) (2.) Important note: Slightly tighten the nuts (2 x part 17) with your Note fingers. The axle must still turn easily by hand. If the nuts are too tight, the gearbox will lock. In this case, slightly loosen the nuts.
- Page 12 Find the following parts and lay them out: Apply glue here! Allow glue to dry for 10 min.
- Page 13 Find the following parts and lay them out: 50 mm When the wheels are mounted to the axle, it must turn easily. If the axle is difficult to turn, simply pull the wheels slightly outward until the axle turns freely again.
- Page 14 Glue to solar cell onto the spoiler, connect the cable and attach the wheels. CAUTION: Information for connecting the cables to the solar cell: Slightly loosen the screws, insert the cables in the holes and tighten the screws with minimal force! Do not tighten screws with a screwdriver to avoid shearing the cables!
- Page 15 CONGRATULATIONS - Your racing car is finished and you are ready to race! To ensure your solar racing car will be really fast, it will need pure "fuel" from direct sunlight! The car will therefore run best outside. Or use a halogen lamp indoors to power the solar cell.
- Page 16 Rennauto::1113.html?language raceauto::1113.html?language=nl SOL-EXPERT kits keep you wanting more: detailed instructions, accurately fitting parts, high quality standard! SOL-EXPERT group, C.Repky Mehlisstrasse 19 - D-88255 Baindt Tel.: +49 (0)7502 - 94115-0 - Fax: +49 (0)7502 - 94115-99 info@sol-expert-group.de - www.sol-expert-group.de...
